The Olympus C-2100UZ good points were the 10x stablized zoom, it used
smartmedia and I could share media with the D-510Z, it uses 3rd party flashes
with the appropriate cable, and it uses the standard color space so no
conversion is needed. The Dimage 5 seems to have a slightly better lens
(though at 7x zoom with no stabalization), a focus ring on the lens barrel
instead of using buttons, USB mass storage support, and 2048x1536 resolution.
One of the things that I thought I was giving up by going with the C-2100UZ
instead of the Dimage is the ability to print great 8x10's, but I have made
some 8x10's from walmart.com, and the quality of the prints blew me away. I
looked briefly at the Olympus C-700UZ, but in April, it was the same price as
the C-2100UZ, did not have image stabalization, and I was wanting a camera that
was more 35mm SLR-like.
In addition, the loyality of the C-2100UZ users seemed to indicate that it was
a fun camera, and it sure is. Part of the fun of the camera is its hack-abilty
(note, I'm using hack in the sense of making modifications to something, and
not in the sense of breaking into computer systems). The rest of this page
shows some of the hacks that I have done. Note, my camera is always a work in
progress.
The 49mm lens hood is also from Ritz and is meant to protect the lens from sun
flares. When used with the 49mm UV filter, I get some vignetting when the
camera lens is in the full wide angle position. If I zoom out slightly, it
goes away.
I was in Walmart and saw they had a cheap ($15) Kodakgear (aka Tiffen) set of
52mm UV filter, 52mm circular polarizer, 52mm lens cap, lens cord, and 49mm to
52mm step up ring. I had been wanting to get a circular polarizing filter, and
this seemed to be cheaper than buying a standalone filter. The polarizing
filter deepens blue skies, reduces the amount of light reaching the lens by 2
f-stops, and eliminates glare and reflections. I no longer use this filter
set, since the vignetting with the 49mm->52mm step-up ring is worse than
using 49mm filters.
I was in a local Ritz store and they had a clearance sale on the A series Cokin
portrait starter kit that included a 52mm holder, diffuser filter, sepia
filter, and a spot filter with orange and yellow spots outside of the center
spot. Unlike round filters that you screw in and need to get different sized
filters based on the lens, the Conkin system uses only 3 different sized
filters (A, P, and X-Pro), and use different holders to match each lens. The
filters seem to be cheaper than buying the screw mounted filters, especially as
you go up to the larger sizes, and you can change them fairly quickly. Because
they don't have a ring around the filter, I have noticed that I am more likely
to get finger prints on the filter. Other than trying out the filters, I
haven't done anything with the Cokin filters, and am contemplating selling
them. I like the Cokin system in theory, since it saves you from having to buy
multiple filters, but the set I have is the Cokin A series, and I would need to
get the Cokin P series in order to share the filters between the normal lens,
the A-200 tele-extender zoom lens, and if I ever get a wide angle
tele-extender.
After going on a trip to the Sterling Renaissance Faire in New York (which on
the day we went was rather dusty) and having to keep the filters clean, I
picked up a Sima lens pen to clean the filters.
After getting a generic 49mm lens hood from Ritz, I was looking around for a
better hood. I found the Hoya Multi-Angle lens hood that is much larger than
the Ritz hood. It has 3 positions of depth, so that I can better reduce flare
when shooting. At the Sterling Renaissance Faire during the final show, the
sun sets behind the stage, and I could see a dramatic difference the lens hood
made when I was taking pictures and raised/lowered the hood. I first
discovered the Hoya Multi-Angle lens hood from "The Filter
Connection" (http://www.2filter.com).
I discovered that the Hoya 49mm lens hood is 72mm on the outside, and the lens
cap from the A-200 tele-extender fits perfectly on it. When I was rumaging
through the camera store, I picked up the OP/tech USA 72mm lens cap that
doesn't dangle from a lens leash, and now use it at the end of the lens hood.
After experiencing vignetting with the Kodakgear 52mm filter set, I went out
and bought a Promaster 49mm linear polarizer filter. I also have bought a 4
point star filter but haven't yet used it, and a used +3 close-up filter. The
close-up filter came with a +1 and a +2 filter too, but the filters were jammed
together and I couldn't separate them. I also bought a set of lens caps to
keep the filters together.
I found that using the filter stack caps to change filters was taking too much
time, so I got some Tamrac filter wallets. The large 8 filter wallet fits
nicely in the side pocket of my Ritz bag, while the small 3 filter wallet fits
on top of the Lowepro TLZ mini bag when I need to reduce the weight.
Both the cables are ~$40 each and the bracket is ~$60. The advantange of the
FL-CB01 and FL-BK01 approach is that you can upgrade to the Olympus flash,
FL-40, which works better with the camera, but is ~$300. However, I was
starting to run into my budget amount and couldn't go with the Oly bracket.
The first flash that I bought (Sunpak 144PC), the pc-sync cable did not match
with the FL-CB04 cable, and I eventually went out and got another flash
(Kalimar 175A) at a local camera store that did work great.
The first bracket I got was a generic L bracket from B&H, and the cold-shoe on
the bracket was screwed in the frame. Over a few weeks, one of the screws came
out, and the other two were lose, so I went and got the Promaster bracket,
which is real solid.
After I got the Lowepro vidcam3 bag and started carrying the camera in it all
of the time, it became a chore to take flash pictures, since I had to
reconstruct the bracket, screw in the camera, take the picture, and undo all of
that. Also, the Promaster bracket has the flash off on the side instead of
over the camera, which means you get shadows to the left. I searched through
the brackets at the local camera store, and found the Stroboflip VH2000 which
is small enough that I can leave it on the camera all of the time without the
flash, and centers the flash over the lens, and the whole rig fits in the bag.
It also flips the flash from horizontal and vertical position like most
Stroboframe flashes (though it rotates the flash and not the camera unlike the
higher end Stroboframe brackets). In the C-2100UZ case, since the tripod hole
is off center, the flash is also slightly off center.
I discovered that the Sima SVR quick release is small enough so that it fits on
the camera and does not have to be removed in order to change the batteries. I
now have two of the quick release mechanisms, one that sits on the camera and
the bracket, and the other one for my two tripods, so that I can move the whole
bracket assembly to either the Ultrapod mini-tripod or the Vivitar full sized
tripod easily.
One of the concerns I had about the Stoboflip flash bracket is the flash is
fairly close to the lens. I found a no-name mini-ball head extender at the
photo store that raises up the flash and allows me to better position the
flash. Unfortunately the screws eventually came out of the flash head, just
like my first bracket. I replaced it with a Hakuba strobe extender that
I picked up in a local camera store that allows me to position the flash at any
angle and it is longer and more solid than the mini-ball head extender it
replaced.
After playing around with the Stoboflip, I was still getting green eyed monster
cats in some cases where it was impractical to bounce light off of the ceiling
(either outdoors, or in our dining room with its 2 story cathedral ceiling). I
ran across the Lumiquest MidiBouncer that attaches to the outside of the flash.
You aim the flash straight up, and the light bounces off the white vinyl and
towards your subject, giving a much softer, diffuse light. Unfortunately, when
I was at the store, the salesguy didn't ask what size flash I had, and the
MidiBouncer is made for the larger flashes like the Vivitar 285HV. It works on
my flash, but I could have gotten the pocket bouncer, which is smaller (they
were within a $1 or $2), and would fit easier in my camera case. The
MidiBouncer does add a lot of height to the camera, and it does reduce the
distance the flash supports by 2.5 times, so I tend to use it when I can't
bounce the light. However, when I upgraded to the larger Promaster
flash, the midi-bouncer fit perfectly.
I did a photo shoot for a storyteller convention and became unhappy with the
amount of light I was getting out of the Midi-bouncer, so I went and got
a Lumiquest mini-soft box on the recomendation of one of the local
camera retailers. It acts as a diffuser instead of a bouncer to produce softer
light.
I wanted to start playing around with reflected light, so I bought a gold and
white Photoflex reflector at a local camera store.
Picture #1: Kalimar 175A flash, Olympus FL-CB04 cable
Small: 800x623, 54,656 bytes (54K), (html file)
Large: 1600x1200, 1,154,009 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/60 sec, 15.2mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 84.0mm
Taken by Michael Meissner on June 08, 2002 00:52:05
Last modified on June 08, 2002 at 11:58
|
Picture #2: Promaster flash bracket
Small: 800x623, 53,828 bytes (53K), (html file)
Large: 1600x1200, 1,183,937 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/60 sec, 13.4mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 74.0mm
Taken by Michael Meissner on June 08, 2002 00:52:35
Last modified on June 08, 2002 at 11:59
|
Picture #3: C-2100UZ with external flash
Small: 800x623, 72,165 bytes (71K), (html file)
Large: 1600x1200, 1,298,958 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.4, ISO 200, flash, 1/40 sec, 7.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 50.0mm
Taken by Michael Meissner on June 08, 2002 00:57:45
Last modified on June 08, 2002 at 12:01
|
Picture #4: Detail of C-2100UZ flash setup
Small: 800x623, 48,643 bytes (48K), (html file)
Large: 1600x1200, 1,111,020 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.9, ISO 200, flash, 1/60 sec, 10.9mm, auto mode, SHQ, spot metering
35mm equivalent focal length 71.0mm
Taken by Michael Meissner on June 08, 2002 00:58:34
Last modified on June 08, 2002 at 12:03
|
Picture #5: C-2100UZ with external flash #2
Small: 600x823, 70,499 bytes (69K), (html file)
Large: 1200x1600, 1,276,771 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.9, ISO 200, flash, 1/60 sec, 10.9mm, auto mode, SHQ, spot metering
35mm equivalent focal length 71.0mm
Taken by Michael Meissner on June 08, 2002 00:59:03
Last modified on June 08, 2002 at 12:06
|
Picture #6: Stoboframe Stoboflip VH2000 bracket in horizontal orientation
Small: 600x846, 70,224 bytes (69K), (html file)
Large: 1200x1600, 1,187,256 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.7, ISO 100, flash, 1/50 sec, 8.9mm, auto mode, SHQ, spot metering
35mm equivalent focal length 58.0mm
Taken by Michael Meissner on July 20, 2002 01:19:09
Last modified on July 20, 2002 at 11:41
|
Picture #7: Stoboframe Stoboflip VH2000 bracket in horizontal orientation #2
Small: 800x623, 68,682 bytes (68K), (html file)
Large: 1600x1200, 1,171,116 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.5, ISO 100, flash, 1/50 sec, 8.0mm, auto mode, SHQ, spot metering
35mm equivalent focal length 52.0mm
Taken by Michael Meissner on July 20, 2002 01:19:26
Last modified on July 20, 2002 at 11:44
|
Picture #8: Stoboframe Stoboflip VH2000 bracket
Small: 600x846, 65,734 bytes (65K), (html file)
Large: 1200x1600, 1,235,791 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 20.7mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on July 20, 2002 01:48:19
Last modified on July 20, 2002 at 11:49
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #9: Lumiquest Promax MidiBouncer and flash mini ball-head extender
Small: 600x846, 87,906 bytes (86K), (html file)
Large: 1200x1600, 1,506,955 bytes (1.4M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 400, flash, 1/60 sec, 14.7mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 82.0mm
Taken by Michael Meissner on August 13, 2002 02:09:07
Last modified on August 13, 2002 at 15:23
|
Picture #10: Promaster 5750DX flash
Small: 600x823, 92,839 bytes (91K), (html file)
Large: 1200x1600, 1,188,113 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/30 sec, 7.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on September 20, 2002 23:16:01
Last modified on September 20, 2002 at 23:50
|
Picture #11: Promaster 5750DX flash on camera, rear view
Small: 600x846, 91,179 bytes (90K), (html file)
Large: 1200x1600, 1,061,752 bytes (1.0M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.7, ISO 100, flash, 1/50 sec, 8.9mm, auto mode, SHQ, spot metering
35mm equivalent focal length 58.0mm
Taken by Michael Meissner on September 20, 2002 23:10:14
Last modified on September 20, 2002 at 23:52
|
Picture #12: Promaster 5750DX flash on camera, front view
Small: 600x846, 91,218 bytes (90K), (html file)
Large: 1200x1600, 1,085,326 bytes (1.0M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.7, ISO 100, flash, 1/50 sec, 8.9mm, auto mode, SHQ, spot metering
35mm equivalent focal length 58.0mm
Taken by Michael Meissner on September 20, 2002 23:10:36
Last modified on September 20, 2002 at 23:52
|
Picture #13: Promaster 5750DX vs. Kalimar 175A
Small: 600x846, 89,036 bytes (87K), (html file)
Large: 1200x1600, 1,956,489 bytes (1.9M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 11.0mm, auto mode, SHQ, matrix metering, bias -0.7
35mm equivalent focal length 61.0mm
Taken by Michael Meissner on October 03, 2002 23:44:43
Last modified on October 03, 2002 at 23:51
|
Picture #14: Promaster 5750DX flash + Olympus 9901 module
Small: 800x623, 96,010 bytes (94K), (html file)
Large: 1600x1200, 1,344,297 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 10.7mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 59.0mm
Taken by Michael Meissner on October 05, 2002 10:48:14
Last modified on October 05, 2002 at 22:01
|
Picture #15: Promaster 5750DX flash, Olympus adapter, standard adapter, and Stoboflip bracket
Small: 800x646, 104,637 bytes (103K), (html file)
Large: 1600x1200, 1,335,726 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/20 sec, 12.7mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 70.0mm
Taken by Michael Meissner on November 28, 2002 09:36:35
Last modified on November 28, 2002 at 10:08
|
Picture #16: Kalimar 175A flash with Wein peanut slave trigger
Small: 600x846, 76,214 bytes (75K), (html file)
Large: 1200x1600, 1,070,387 bytes (1.0M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/100 sec, 22.3mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 124.0mm
Taken by Michael Meissner on November 28, 2002 11:00:57
Last modified on November 28, 2002 at 11:13
|
Picture #17: Flash accessories
Small: 800x623, 64,306 bytes (63K), (html file)
Large: 1600x1200, 1,439,104 bytes (1.4M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/8.0, ISO 100, 1/2 sec, 7.0mm, aperture priority, SHQ, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on April 09, 2003 13:25:39
Last modified on April 09, 2003 at 13:36
|
Picture #18: Flash extender
Small: 800x623, 44,724 bytes (44K), (html file)
Large: 1600x1200, 983,970 bytes (961K), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/50 sec, 11.3mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 63.0mm
Taken by Michael Meissner on April 09, 2003 12:13:40
Last modified on April 09, 2003 at 13:54
|
Picture #19: Mini softbox
Small: 600x823, 43,173 bytes (43K), (html file)
Large: 1200x1600, 970,344 bytes (948K), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/30 sec, 7.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on April 09, 2003 12:15:58
Last modified on April 09, 2003 at 13:55
|
Picture #20: Photoflex reflector
Small: 800x623, 73,873 bytes (73K), (html file)
Large: 1600x1200, 1,166,789 bytes (1.1M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/80 sec, 13.0mm, auto mode, SHQ, sunny, matrix metering
35mm equivalent focal length 72.0mm
Taken by Michael Meissner on August 27, 2003 13:26:40
Last modified on August 27, 2003 at 13:57
|
Picture #21: Using the flash on a secondary tripod + using TV output
Small: 800x623, 76,249 bytes (75K), (html file)
Large: 1600x1200, 1,056,224 bytes (1.0M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on September 17, 2003 12:58:32
Last modified on September 17, 2003 at 13:14
|
Picture #22: Using the flash on a secondary tripod + using TV output #2
Small: 600x846, 67,357 bytes (66K), (html file)
Large: 1200x1600, 1,220,381 bytes (1.2M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus D-510Z camera
f/3.9, ISO 100, flash, 1/60 sec, 10.5mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 68.0mm
Taken by Michael Meissner on September 17, 2003 12:58:49
Last modified on September 17, 2003 at 13:15
|
Picture #23: Savage economy background stand and background paper
Small: 600x846, 59,504 bytes (59K), (html file)
Large: 1200x1600, 1,158,359 bytes (1.1M), (html file)
Copyright, Michael Meissner 2004, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/30 sec, 7.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on February 09, 2004 13:37:12
Last modified on February 10, 2004 at 09:09
|
Picture #24: Photoflex flash/umbrella clamp and Photoflex 45" white umbrella
Small: 600x846, 59,140 bytes (58K), (html file)
Large: 1200x1600, 1,029,847 bytes (1006K), (html file)
Copyright, Michael Meissner 2004, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/30 sec, 7.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on February 09, 2004 13:19:13
Last modified on February 10, 2004 at 10:56
|
Picture #25: Setup for pink fluffy bunny shot from the 2004-04 album
Small: 800x623, 67,877 bytes (67K), (html file)
Large: 1600x1200, 1,024,735 bytes (1001K), (html file)
Copyright, Michael Meissner 2004, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/250 sec, 7.0mm, shutter priority, SHQ, cloudy, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on April 10, 2004 17:34:12
Last modified on April 11, 2004 at 08:34
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #26: C-2100UZ with Stroboframe Pro-RL fully extended
Small: 480x686, 39,694 bytes (39K), (html file)
Large: 1920x2560, 3,645,589 bytes (3.5M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/3.5, ISO 400, 1/80 sec, 27.0mm, auto mode, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 54.0mm
Taken by Michael Meissner on August 13, 2005 11:33:36
Last modified on August 13, 2005 at 12:14
|
Picture #27: C-2100UZ with Stroboframe Pro-RL flash at the lowest position
Small: 480x686, 40,464 bytes (40K), (html file)
Large: 1920x2560, 3,557,186 bytes (3.4M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/3.2, ISO 400, 1/60 sec, 27.0mm, auto mode, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 54.0mm
Taken by Michael Meissner on August 13, 2005 11:34:12
Last modified on August 13, 2005 at 12:18
|
Picture #28: Promaster 5750DX flash, E-1 adaptor, ST adaptor, and 5 pin adaptor
Small: 480x686, 50,584 bytes (50K), (html file)
Large: 1920x2560, 1,234,725 bytes (1.2M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/4.0, ISO 100, FL-50 flash, 1/160 sec, 52.0mm, manual mode, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 104.0mm
Extra equipment used: FL-50
Taken by Michael Meissner on January 01, 2006 20:59:30
Last modified on January 01, 2006 at 21:05
|
Picture #29: Samigon flash bracket, landscape mode, minimum flash height
Small: 600x846, 61,713 bytes (61K), (html file)
Large: 1200x1600, 1,572,251 bytes (1.5M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/50 sec, 12.0mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 67.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on July 26, 2006 08:27:13
Last modified on July 26, 2006 at 08:47
|
Picture #30: Samigon flash bracket, portrait orientation, minimum height
Small: 600x846, 62,739 bytes (62K), (html file)
Large: 1200x1600, 1,500,771 bytes (1.4M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/60 sec, 14.3mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 79.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on July 26, 2006 08:28:23
Last modified on July 26, 2006 at 08:47
|
Picture #31: Samigon flash bracket, back view, minimum height, SHLD-2
Small: 600x846, 65,101 bytes (64K), (html file)
Large: 1200x1600, 1,508,899 bytes (1.4M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/60 sec, 16.2mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 90.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on July 26, 2006 08:32:04
Last modified on July 26, 2006 at 08:47
|
Picture #32: Samigon flash bracket, landscape mode, maximum height
Small: 600x846, 57,411 bytes (57K), (html file)
Large: 1200x1600, 1,627,654 bytes (1.6M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/40 sec, 9.4mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 52.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on July 26, 2006 08:33:56
Last modified on July 26, 2006 at 08:47
|
Picture #33: Samigon flash bracket, 45" umbrella
Small: 400x646, 44,325 bytes (44K), (html file)
Large: 800x1200, 948,829 bytes (927K), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/4.0, ISO 100, 1/30 sec, 7.0mm, aperture priority, SHQ, cloudy, matrix metering
35mm equivalent focal length 39.0mm
Extra equipment used: Promaster 5750DX flash, Flip-it
Taken by Michael Meissner on July 26, 2006 08:40:46
Last modified on July 26, 2006 at 08:47
|
Picture #34: Samigon bracket diassembled + EMS bag for storage
Small: 640x526, 89,669 bytes (88K), (html file)
Large: 2560x1920, 5,687,017 bytes (5.4M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/3.4, ISO 100, FL-50 flash, 1/100 sec, 49.0mm, auto mode, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 98.0mm
Extra equipment used: FL-50 flash
Taken by Michael Meissner on July 26, 2006 12:15:17
Last modified on July 26, 2006 at 12:18
|
Picture #35: Olympus C-2100UZ in Stroboframe Pro-rl bracket, landscape orientation
Small: 640x526, 59,552 bytes (59K), (html file)
Large: 2560x1920, 3,656,427 bytes (3.5M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-50 flash, 1/100 sec, 51.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 102.0mm
Extra equipment used: FL-50 flash
Taken by Michael Meissner on April 07, 2007 22:05:19
Last modified on April 07, 2007 at 22:05
|
Picture #36: Olympus C-2100UZ in Stroboframe Pro-rl bracket, portrait orientation
Small: 640x526, 53,105 bytes (52K), (html file)
Large: 2560x1920, 3,440,178 bytes (3.3M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-50 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: FL-50 flash
Taken by Michael Meissner on April 07, 2007 22:05:43
Last modified on April 07, 2007 at 22:05
|
Picture #37: Olympus C-2100UZ in Stroboframe Pro-rl bracket, portrait orientation #2
Small: 480x686, 55,922 bytes (55K), (html file)
Large: 1920x2560, 3,960,964 bytes (3.8M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-50 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: FL-50 flash
Programs used: rotate
Taken by Michael Meissner on April 07, 2007 22:07:02
Last modified on April 07, 2007 at 22:07
|
Picture #38: Promaster ring flash on E-510, 50mm lens
Small: 600x846, 84,793 bytes (83K), (html file)
Large: 1800x2400, 2,442,331 bytes (2.3M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, FL-50 flash (+0.7 flash compensation), 1/60 sec, 33.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 66.0mm
Extra equipment used: FL-50 flash
Programs used: RAW, gimp
Taken by Michael Meissner on March 16, 2008 19:11:47
Last modified on March 16, 2008 at 19:28
|
Picture #39: Promaster ring flash on E-510, 50mm lens #2
Small: 640x526, 66,872 bytes (66K), (html file)
Large: 2560x1920, 4,275,394 bytes (4.1M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, FL-50 flash (+0.7 flash compensation), 1/40 sec, 22.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 44.0mm
Extra equipment used: FL-50 flash
Programs used: gimp
Taken by Michael Meissner on March 16, 2008 19:34:12
Last modified on March 16, 2008 at 19:49
|
Picture #40: Picture of the FL-36, FL-50, Promaster flash shoes
Small: 656x538, 83,725 bytes (82K), (html file)
Large: 2624x1966, 3,977,585 bytes (3.8M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/16.0, ISO 100, Promaster flash (+1 flash compensation), 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: Promaster ring flash
Programs used: RAW, gimp
Taken by Michael Meissner on May 21, 2008 09:15:33
Last modified on May 21, 2008 at 09:25
|
Picture #41: C-2100UZ and Promaster ring flash
Small: 656x515, 53,663 bytes (53K), (html file)
Large: 2624x1966, 2,208,084 bytes (2.1M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/5.6, ISO 100, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: FL-36 flash
Programs used: RAW, gimp
Taken by Michael Meissner on May 23, 2008 07:04:44
Last modified on May 23, 2008 at 07:13
|
Picture #42: Deconstructed flash cable
Small: 800x623, 52,082 bytes (51K), (html file)
Large: 3200x2400, 5,332,991 bytes (5.1M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 50mm f/2.0 lens
f/11.0, ISO 500, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 100.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on July 02, 2010 08:32:27
Last modified on July 02, 2010 at 08:43
|
Picture #43: Four flashes
Small: 900x473, 72,603 bytes (71K), (html file)
Large: 3600x1800, 5,706,608 bytes (5.4M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/60 sec, 27.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 54.0mm
Extra equipment used: onboard flash
Programs used: gimp
Taken by Michael Meissner on March 15, 2011 09:30:42
Last modified on March 15, 2011 at 21:50
From left to right:
- Olympus FL-36
- Metz 48 AF-1
- Olympus FL-50
- Promaster 5750DX
|
Picture #44: Four flashes #2
Small: 900x473, 73,480 bytes (72K), (html file)
Large: 3600x1800, 5,747,503 bytes (5.5M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/60 sec, 28.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 56.0mm
Extra equipment used: onboard flash
Programs used: gimp
Taken by Michael Meissner on March 15, 2011 09:31:29
Last modified on March 15, 2011 at 21:55
From left to right:
- Olympus FL-36
- Metz 48 AF-1
- Olympus FL-50
- Promaster 5750DX
|
Picture #45: Four flashes #3
Small: 900x473, 82,051 bytes (81K), (html file)
Large: 3600x1800, 6,376,548 bytes (6.1M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/60 sec, 23.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 46.0mm
Extra equipment used: onboard flash
Programs used: gimp
Taken by Michael Meissner on March 15, 2011 09:31:58
Last modified on March 15, 2011 at 21:57
|
After buying the Radio Shack holder, I discovered CompUSA had a larger media
holder from Case Logic for ~$6 that allowed me to hold 4 smart media cards, my
49->52mm step-up ring and 52mm polarizer. I did move over the ring and
media case from the Radio Shack holder to the Case Logic holder. I can't find
this particular case on the CompUSA site.
When I was in a local camera store, I saw the media holders from OP/tech USA
that can hold 2 batteries or media cards. I bought the 2 that they had to add
4 more batteries on the camera strap. However, I'm not sure I would trust the
somewhat fragile smartmedia cards in this holder. The optech link is available
here.
As I was looking over various web sites, I saw one media or battery holder that
had an indicator of whether the item was full or empty. This seemed like a
good idea, so I made up a set of paper inserts to fit in the plastic smartmedia
case to indicate the storage amount and whether it empty or full.
I use a Rayovac 1 hour charger to charge the batteries that I got at Walmart.
I like the fact that unlike other chargers, it has separate sensors for each
individual battery being charged, instead of having one sensor for groups of 2
or 4 batteries. Note, the batteries do get hot in the Rayovac charger.
I use Linux as my primary operating system, and the C-2100UZ does not act like
a removable hard drive when plugged into the USB bus like newer cameras
(including the D-510Z). The Omniflash reader supports both read and write
operations in Linux. I got my reader from
Compuapps.
After seeing the slim Case Logic media holders in the store, I decided to buy
one. I've moved all of my media cards to this, and put a third set of
batteries in the other Case Logic I bought previously.
I occasionally got corruption on my smart media cards after using the Omniflash
reader, even if I tell the OS to mount it read-only. So when I was in
Microcenter, I noticed that the Dazzle pcmcia card was fairly cheap, so I got
it. It works well to copy the data, though I do have to swap out my wireless
pcmcia card when copying the data (the builtin wireless ethernet in my laptop
seems to have stabality problems, so it is simpler to use a wireless pcmcia
card to connect to the network). I did some tests, and the pcmcia card is
about 40% faster than the Omniflash USB card if the system is running off of
the wall current, and somewhat slower when running on battery power.
The Image Bank is a portable hard disk that runs on either batteries, auto
current, or wall current. When you place a smartmedia or compactflash card in
the appropriate slot, and press the copy button it will copy the contents of
the media card to a new directory on the hard disk. Each time you do the copy
operation, it creates a new directory. Later when you plug the USB cable into
the Image Bank and connect it to a computer, it acts like a normal USB hard
drive. I find that Linux (through revision 2.4.22) does not deal with the
Image Bank, and I have to boot my machine into Windows to do the copy. I
bought the older system with a 3.2 gigabyte disk.
In February 2003, I took a vacation to the Grand Canyon, and planned to take my
Image Bank with me. I found it immediately shut down when I attempted
to copy media cards, though it would work fine as a USB disk. After the trip,
I replaced it with the Vosonic
X-drive II. I discovered later, that the Image Bank would go
brain dead like mine if you used it as a USB disk and created new directories
(which I had done). The original firmware of the X-drive II has a bug
in it that any vibration of the unit while the copying is going on will
immediately abort the transfer (but at least it tells you the transfer was
aborted, unlike the Image Bank which just shuts down to signal an
error). The firmware upgrade process is extremely clunky, and Vosonic
doesn't provide support for their products, so if you are in the market for a
portable hard drive, you might think about other models. Linux version
2.4.21 and above has support for the X-drive II.
Picture #1: Radio Shack flash card/battery holder
Small: 800x623, 56,058 bytes (55K), (html file)
Large: 1600x1200, 1,203,705 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 20.0mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 111.0mm
Taken by Michael Meissner on June 08, 2002 01:13:16
Last modified on June 08, 2002 at 12:07
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #2: Homemade empty/full indicators for smartmedia
Small: 800x623, 74,940 bytes (74K), (html file)
Large: 1600x1200, 1,325,187 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 20.7mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on June 08, 2002 01:16:07
Last modified on June 08, 2002 at 12:09
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #3: Rayovac 1 hour charger + 4 Nimh batteries
Small: 800x623, 43,075 bytes (43K), (html file)
Large: 1600x1200, 1,096,698 bytes (1.0M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 24.2mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 134.0mm
Taken by Michael Meissner on June 08, 2002 01:18:13
Last modified on June 08, 2002 at 12:11
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #4: Omniflash Uno! smartmedia USB reader
Small: 800x623, 55,195 bytes (54K), (html file)
Large: 1600x1200, 1,154,233 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/60 sec, 15.2mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 84.0mm
Taken by Michael Meissner on June 08, 2002 02:05:51
Last modified on June 08, 2002 at 21:00
|
Picture #5: Case Logic battery and media holder
Small: 800x623, 93,959 bytes (92K), (html file)
Large: 1600x1200, 1,252,743 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 13.4mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 74.0mm
Taken by Michael Meissner on June 12, 2002 09:15:32
Last modified on June 12, 2002 at 12:40
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #6: Op/tech USA media holster
Small: 800x623, 79,810 bytes (78K), (html file)
Large: 1600x1200, 1,004,428 bytes (981K), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 14.3mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 79.0mm
Taken by Michael Meissner on June 12, 2002 12:53:59
Last modified on June 12, 2002 at 12:58
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #7: Case Logic media holder
Small: 600x823, 97,722 bytes (96K), (html file)
Large: 1200x1600, 1,295,478 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 24.2mm, manual mode, SHQ, matrix metering, macro
35mm equivalent focal length 134.0mm
Taken by Michael Meissner on September 02, 2002 10:04:48
Last modified on September 02, 2002 at 11:08
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #8: Case Logic media holder #2
Small: 600x823, 74,637 bytes (73K), (html file)
Large: 1200x1600, 1,930,805 bytes (1.8M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 16.8mm, manual mode, SHQ, matrix metering, macro
35mm equivalent focal length 93.0mm
Taken by Michael Meissner on September 02, 2002 10:06:55
Last modified on September 02, 2002 at 11:09
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #9: Dazzle pcmcia smart media reader/writer
Small: 600x846, 81,595 bytes (80K), (html file)
Large: 1200x1600, 1,244,067 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/100 sec, 24.2mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 134.0mm
Taken by Michael Meissner on October 04, 2002 23:56:55
Last modified on October 05, 2002 at 01:12
|
Picture #10: Image Bank portable media storage
Small: 800x623, 102,727 bytes (101K), (html file)
Large: 1600x1200, 1,337,435 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/50 sec, 11.6mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 64.0mm
Taken by Michael Meissner on October 05, 2002 01:17:56
Last modified on October 05, 2002 at 01:44
|
Picture #11: Components of the Image Bank
Small: 800x623, 89,665 bytes (88K), (html file)
Large: 1600x1200, 1,184,515 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/60 sec, 13.4mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 74.0mm
Taken by Michael Meissner on November 22, 2002 22:15:17
Last modified on November 22, 2002 at 22:21
|
Picture #12: Drifter Bags battery cases
Small: 800x623, 107,218 bytes (105K), (html file)
Large: 1600x1200, 1,234,120 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/8.0, ISO 100, 1/60 sec, 15.7mm, aperture priority, SHQ, matrix metering
35mm equivalent focal length 87.0mm
Taken by Michael Meissner on December 21, 2002 12:27:03
Last modified on December 21, 2002 at 12:35
|
Picture #13: X-drive II
Small: 800x623, 62,366 bytes (61K), (html file)
Large: 1600x1200, 938,747 bytes (917K), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/80 sec, 16.8mm, auto mode, SHQ, sunny, matrix metering
35mm equivalent focal length 93.0mm
Taken by Michael Meissner on August 27, 2003 13:24:12
Last modified on August 27, 2003 at 13:53
|
Picture #14: Lightning 4000N charger and Sanyo 2100 maH batteries
Small: 800x623, 75,741 bytes (74K), (html file)
Large: 1600x1200, 1,088,095 bytes (1.0M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/80 sec, 18.6mm, auto mode, SHQ, matrix metering, macro
35mm equivalent focal length 103.0mm
Taken by Michael Meissner on August 27, 2003 14:00:16
Last modified on August 27, 2003 at 14:32
|
Picture #15: C-2100UZ with DPS-9000 battery attached on the side
Small: 640x526, 48,395 bytes (48K), (html file)
Large: 2560x1920, 5,133,912 bytes (4.9M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus E-1 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, ext. flash, 1/160 sec, 33.0mm, manual mode, SHQ, matrix metering, -2 contrast, +2 sharpening, manual focus
35mm equivalent focal length 66.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on February 22, 2005 09:00:22
Last modified on August 28, 2005 at 11:50
|
Picture #16: Lots of electronic gear to carry on trips
Small: 640x503, 57,994 bytes (57K), (html file)
Large: 2560x1920, 5,424,371 bytes (5.2M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/2.0, ISO 100, 1/50 sec, 50.0mm, auto mode, SHQ, matrix metering, -2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Taken by Michael Meissner on June 29, 2005 22:33:54
Last modified on July 06, 2005 at 09:21
|
Picture #17: Battery wallet from greenbatteries.com
Small: 800x623, 124,204 bytes (122K), (html file)
Large: 3200x2400, 8,920,459 bytes (8.5M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash, 1/100 sec, 54.0mm, aperture priority, vivid color, auto gradation, matrix metering, image stabilization
35mm equivalent focal length 108.0mm
Extra equipment used: Pop-up flash
Programs used: gimp
Taken by Michael Meissner on May 19, 2010 11:11:41
Last modified on May 19, 2010 at 19:24
|
Picture #18: Battery wallet from greenbatteries.com #2
Small: 800x623, 132,568 bytes (130K), (html file)
Large: 3200x2400, 8,736,931 bytes (8.3M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash, 1/100 sec, 54.0mm, aperture priority, vivid color, auto gradation, matrix metering, image stabilization
35mm equivalent focal length 108.0mm
Extra equipment used: Pop-up flash
Programs used: gimp
Taken by Michael Meissner on May 19, 2010 11:12:20
Last modified on May 19, 2010 at 19:25
|
Picture #19: Cell phone and external USB battery charger
Small: 600x846, 96,814 bytes (95K), (html file)
Large: 1200x1600, 1,993,846 bytes (1.9M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/100 sec, 22.3mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 124.0mm
Extra equipment used: Pop-up flash
Programs used: gimp
Taken by Michael Meissner on June 11, 2010 09:32:54
Last modified on June 11, 2010 at 10:14
|
Any way, I liked the idea of interchangable straps, so I got Tamrac N-17
(normal strap) and N-11 (two small straps that are meant to attach to D-rings
on a backpack) straps which have the quick release facility. I can now quickly
change the strap from being on the camera itself, to being on the camera and
flash bracket, to being on the camera bag to being off completely when it is on
the tripod. I do wish I had sprung for the extra money and went for
the N-25 or N-27 straps, which are wider and have neoprene shock absorber.
Originally, I used a small dog collar for attaching to the flash bracket, but
that wasn't tight enough, so I then used two layers of velcro straps to make it
fit better. Eventually the adhesive on the velcro wouldn't stick to the dog
collar, so I got a velcro strap with a D-ring from a computer store (it was
meant to keep cables together) and stapled another velcro strip on the inside,
which mates with the velcro strip that was glued around the top of the flash
bracket.
I used a velcro strip to wrap around the flash to keep the pc-sync cable in the
flash, and to keep the pc-sync cable attached to the FL-CB04 cable.
I am rather nervous about having the camera accidently falling, so I also added
a wrist strap for holding the camera when I don't have the neck strap on. I
originally bought the Tamrac N-15 hand strap but it is a hand strap and not a
wrist strap (ie, it isn't tight around my wrist, so the camera could still fall
off). I first made a wrist strap out of a small dog collar and attached one of
the N-11 straps to it. Now, when the camera is on my neck, I detach the wrist
strap using the quick release mechansim, and when I'm holding the camera, I
attach it back again.
When I was in a camera store looking for camera bags, I saw the OP/TECH USA
gotcha wrist strap, which uses velcro to attach, rather than a clasp. The
velcro is a lot easier to attach and detach than the clasps of the dog collar,
particularly on my right wrist, since I am right handed, and it meant doing it
with my left hand. OP/TECH uses a female quick release connector while the
Tamrac straps use a male connector, so I can't use the same strap for both.
The OP/TECH USA web site for the gotcha strap is located
here.
I find I use the wrist strap much more than I use the neck strap these days.
I used velcro strips to keep the pc-sync cord attached to both the flash and
the FL-CB04 cable, since it would come out every so often until I upgraded to
the Promaster flash, which provides its own cord.
I got some twist rings from the local hardware store so that the straps won't
get twisted, but they are not easy to remove. I was in the outdoor store
REI and they had some zipper pulls by the cash register. I got these
and now use them instead of the twist rings, because they are easy to attach
and detach, and when detached, they don't leave bits still on the camera.
Picture #1: Tamrac N-11 strap + dog collar as wrist strap
Small: 800x623, 50,043 bytes (49K), (html file)
Large: 1600x1200, 1,138,520 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 20.7mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on June 08, 2002 01:21:05
Last modified on June 08, 2002 at 12:14
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #2: Tamrac N-17 strap with dog collar to attach to flash bracket
Small: 800x623, 75,915 bytes (75K), (html file)
Large: 1600x1200, 1,369,329 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 17.3mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 96.0mm
Taken by Michael Meissner on June 08, 2002 01:22:03
Last modified on June 08, 2002 at 12:16
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #3: Shoulder and wrist straps on C-2100UZ
Small: 800x623, 77,425 bytes (76K), (html file)
Large: 1600x1200, 1,348,719 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.7, ISO 200, flash, 1/50 sec, 9.3mm, auto mode, SHQ, spot metering
35mm equivalent focal length 61.0mm
Taken by Michael Meissner on June 08, 2002 01:36:53
Last modified on June 08, 2002 at 12:18
|
Picture #4: Shoulder and wrist straps on C-2100UZ with flash bracket
Small: 800x623, 80,297 bytes (79K), (html file)
Large: 1600x1200, 1,354,405 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.5, ISO 200, flash, 1/50 sec, 8.0mm, auto mode, SHQ, spot metering
35mm equivalent focal length 52.0mm
Taken by Michael Meissner on June 08, 2002 01:40:29
Last modified on June 08, 2002 at 12:20
|
Picture #5: Connecting the straps with twist rings
Small: 800x623, 89,700 bytes (88K), (html file)
Large: 1600x1200, 1,345,246 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/4.1, ISO 200, flash, 1/60 sec, 12.5mm, auto mode, SHQ, spot metering
35mm equivalent focal length 82.0mm
Taken by Michael Meissner on June 10, 2002 01:11:07
Last modified on June 10, 2002 at 09:44
|
Picture #6: Connecting the straps with twist rings #2
Small: 800x623, 96,158 bytes (94K), (html file)
Large: 1600x1200, 1,443,797 bytes (1.4M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 200, flash, 1/30 sec, 5.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on June 10, 2002 01:11:31
Last modified on June 10, 2002 at 09:47
|
Picture #7: Velcro strap holder and velcro pc-sync cable holder
Small: 800x623, 59,894 bytes (59K), (html file)
Large: 1600x1200, 1,093,217 bytes (1.0M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/25 sec, 7.0mm, auto mode, SHQ, matrix metering, macro
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on June 20, 2002 12:37:18
Last modified on June 20, 2002 at 20:40
|
Picture #8: OP/TECH USA gotcha wrist strap
Small: 800x623, 94,973 bytes (93K), (html file)
Large: 1600x1200, 1,365,540 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.2, ISO 100, flash, 1/40 sec, 7.0mm, auto mode, SHQ, spot metering
35mm equivalent focal length 46.0mm
Taken by Michael Meissner on June 23, 2002 23:46:53
Last modified on June 24, 2002 at 09:49
|
Picture #9: Zipper pulls on neck/wrist straps
Small: 800x623, 109,443 bytes (107K), (html file)
Large: 1600x1200, 1,223,898 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/8.0, ISO 100, 1/60 sec, 14.7mm, aperture priority, SHQ, cloudy, matrix metering
35mm equivalent focal length 82.0mm
Taken by Michael Meissner on November 28, 2002 09:32:59
Last modified on November 28, 2002 at 09:54
|
Picture #10: Custom wrist strap
Small: 600x823, 35,548 bytes (35K), (html file)
Large: 1200x1600, 958,410 bytes (936K), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/100 sec, 21.5mm, auto mode, SHQ, sunny, matrix metering
35mm equivalent focal length 119.0mm
Taken by Michael Meissner on August 27, 2003 13:22:16
Last modified on August 27, 2003 at 13:41
|
Picture #11: Custom wrist strap #2
Small: 800x623, 45,391 bytes (45K), (html file)
Large: 1600x1200, 1,065,838 bytes (1.0M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/80 sec, 16.8mm, auto mode, SHQ, sunny, matrix metering
35mm equivalent focal length 93.0mm
Taken by Michael Meissner on August 27, 2003 13:22:48
Last modified on August 27, 2003 at 13:41
|
Picture #12: OPtech/USA adapt-it, 1.5" Domke gripper strap on Olympus E-5
Small: 800x623, 90,904 bytes (89K), (html file)
Large: 1600x1200, 745,634 bytes (729K), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/40 sec, 8.6mm, auto mode, SHQ, cloudy, matrix metering, macro
35mm equivalent focal length 48.0mm
Extra equipment used: Pop-up flash
Programs used: raw therapee
Taken by Michael Meissner on April 28, 2012 06:36:42
Last modified on April 28, 2012 at 07:51
|
Picture #13: OPtech/USA adapt-it, 1.5" Domke gripper strap on Olympus E-5 #2
Small: 800x623, 94,203 bytes (92K), (html file)
Large: 1600x1200, 755,511 bytes (738K), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/100 sec, 20.0mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 111.0mm
Extra equipment used: Pop-up flash
Programs used: raw therapee
Taken by Michael Meissner on April 28, 2012 06:46:39
Last modified on April 28, 2012 at 07:51
|
I bought a Case Logic bag from CompUSA that the C-2100UZ fits in rather nicely.
I put it in sitting on the back with the lens up in the air. I must admit
since I've gotten the flash bracket and straps setup, I tend not to use the case
all that much.
My family and I go to Renaissance Faires in costume as part of our vacation,
and at the Georgia Renaissance Faire I picked up a large pouch (sporran model)
from Dreamshoes.com that is
just the perfect size to hold the C-2100UZ, though it doesn't hold the falsh or
bracket well.
After getting some more equipment, I got tired of having all of the other
equipment spill over the shelf, so I went looking for a new camera bag. I
decided on the Lowepro vidcam3 bag, which is large enough for the camera and
all of my current stuff (though it is somewhat of a close fit), with the flash
and bracket in the bottom compartment, the batteries, filters, and smartmedia
cards in the side pocket, and camera and A-200 lens in the top compartment.
The web site for the vidcam3 bag is located
here.
Eventually, the Lowpro bag wasn't enough space, particularly to store the new
Promaster 5750DX flash, so I went to Ritz and bought one of their large
Quantaray QG-BL bags. It measures 8"(W) x 12"(L) x
8"(H).
Picture #1: Olympus case for D-510Z
Small: 800x623, 58,980 bytes (58K), (html file)
Large: 1600x1200, 1,227,362 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 12.3mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 68.0mm
Taken by Michael Meissner on June 08, 2002 00:28:53
Last modified on June 08, 2002 at 11:51
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #2: Case Logic camera bag
Small: 800x623, 80,523 bytes (79K), (html file)
Large: 1600x1200, 1,403,419 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 9.7mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 54.0mm
Taken by Michael Meissner on June 08, 2002 01:50:35
Last modified on June 08, 2002 at 20:53
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #3: Case Logic camera bag #2
Small: 800x623, 85,237 bytes (84K), (html file)
Large: 1600x1200, 1,444,707 bytes (1.4M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 10.7mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 59.0mm
Taken by Michael Meissner on June 08, 2002 01:51:00
Last modified on June 08, 2002 at 20:54
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #4: Case Logic camera bag #3
Small: 800x623, 80,981 bytes (80K), (html file)
Large: 1600x1200, 1,399,250 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 10.7mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 59.0mm
Taken by Michael Meissner on June 08, 2002 01:51:43
Last modified on June 08, 2002 at 20:55
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #5: C-2100UZ in Case Logic camera bag
Small: 800x623, 81,884 bytes (80K), (html file)
Large: 1600x1200, 1,362,213 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.8, ISO 200, flash, 1/50 sec, 10.1mm, auto mode, SHQ, spot metering
35mm equivalent focal length 66.0mm
Taken by Michael Meissner on June 08, 2002 01:53:38
Last modified on June 08, 2002 at 20:57
|
Picture #6: Renaissance Faire pouch for C-2100UZ
Small: 600x846, 80,406 bytes (79K), (html file)
Large: 1200x1600, 1,337,653 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/4.0, ISO 200, flash, 1/60 sec, 11.7mm, auto mode, SHQ, spot metering
35mm equivalent focal length 76.0mm
Taken by Michael Meissner on June 14, 2002 00:53:36
Last modified on June 14, 2002 at 01:02
|
Picture #7: Renaissance Faire pouch for C-2100UZ #2
Small: 800x623, 91,124 bytes (89K), (html file)
Large: 1600x1200, 1,439,492 bytes (1.4M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.8, ISO 200, flash, 1/50 sec, 9.9mm, auto mode, SHQ, spot metering
35mm equivalent focal length 65.0mm
Taken by Michael Meissner on June 14, 2002 00:54:24
Last modified on June 14, 2002 at 01:03
|
Picture #8: Lowepro vidcam3 bag
Small: 600x823, 118,582 bytes (116K), (html file)
Large: 1200x1600, 1,577,239 bytes (1.5M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on June 23, 2002 23:56:54
Last modified on June 24, 2002 at 10:00
|
Picture #9: Lowepro vidcam3 bag #2
Small: 600x717, 96,375 bytes (95K), (html file)
Large: 1200x1388, 1,378,063 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on June 24, 2002 00:00:45
Last modified on June 24, 2002 at 11:08
|
Picture #10: Lowepro vidcam3 bag #3
Small: 800x623, 120,513 bytes (118K), (html file)
Large: 1600x1200, 1,547,957 bytes (1.5M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.4, ISO 100, flash, 1/40 sec, 7.8mm, auto mode, SHQ, spot metering
35mm equivalent focal length 51.0mm
Taken by Michael Meissner on June 24, 2002 11:19:11
Last modified on June 24, 2002 at 11:24
|
Picture #11: Packing the bag #1, Lumiquest bouncer underneath, Promaster flash on side
Small: 800x646, 68,764 bytes (68K), (html file)
Large: 1600x1200, 916,806 bytes (896K), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on September 12, 2002 00:04:18
Last modified on September 12, 2002 at 00:21
|
Picture #12: Packing the bag #2, camera in bracket, A-200 on top of flash, memory cards on side
Small: 800x646, 101,454 bytes (100K), (html file)
Large: 1600x1200, 1,180,264 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on September 12, 2002 00:05:10
Last modified on September 12, 2002 at 00:22
|
Picture #13: Lowepro TLZ mini camera bag
Small: 600x846, 97,454 bytes (96K), (html file)
Large: 1200x1600, 1,318,188 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/60 sec, 14.3mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 79.0mm
Taken by Michael Meissner on October 05, 2002 01:22:48
Last modified on October 05, 2002 at 01:50
|
Picture #14: Ritz Quantaray QG-BL Large bag
Small: 800x623, 101,334 bytes (99K), (html file)
Large: 1600x1200, 1,406,395 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, cloudy, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on November 06, 2002 23:11:25
Last modified on November 06, 2002 at 22:50
|
Picture #15: Ritz Quantaray QG-BL Large bag #2
Small: 800x623, 69,461 bytes (68K), (html file)
Large: 1600x1200, 1,136,258 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/3.0, ISO 100, flash, 1/30 sec, 6.2mm, auto mode, SHQ, cloudy, spot metering
35mm equivalent focal length 40.0mm
Taken by Michael Meissner on November 06, 2002 23:13:20
Last modified on November 06, 2002 at 22:51
|
Picture #16: Rio Bravo fishing vest
Small: 600x823, 43,150 bytes (43K), (html file)
Large: 1200x1600, 1,042,303 bytes (1018K), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/50 sec, 11.0mm, auto mode, SHQ, sunny, matrix metering
35mm equivalent focal length 61.0mm
Taken by Michael Meissner on August 27, 2003 13:10:00
Last modified on August 27, 2003 at 13:33
|
Picture #17: Lowepro Nova 1, E-1, 40-150mm lens, FL-50 flash
Small: 800x623, 76,548 bytes (75K), (html file)
Large: 1600x1200, 1,221,120 bytes (1.2M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/40 sec, 9.0mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 50.0mm
Taken by Michael Meissner on December 23, 2005 08:58:14
Last modified on December 23, 2005 at 09:05
|
Picture #18: Lowepro Nova 1, E-1, 40-150mm lens, FL-50 flash #2
Small: 800x623, 73,314 bytes (72K), (html file)
Large: 1600x1200, 1,193,009 bytes (1.1M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/40 sec, 9.0mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 50.0mm
Taken by Michael Meissner on December 23, 2005 08:58:42
Last modified on December 23, 2005 at 09:05
|
Picture #19: E-1, lenses in Quantary bag
Small: 800x623, 121,462 bytes (119K), (html file)
Large: 1600x1200, 1,242,546 bytes (1.2M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/40 sec, 9.4mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 52.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on January 19, 2006 09:50:46
Last modified on January 23, 2006 at 23:04
In the first row is the E-1, with the 14-54mm lens attached. In the second
row, is the 50mm macro lens, and a Stroboframe folding bracket with a FL-CB05
cord attached. In the third row is the 50-200mm lens and the FL-50 flash. The
FL-50 flash has a Flip-it attached. In the top pocket is a Hoya SMC slim
polarizer, Expocap, and a RM-CB1 wired shutter release.
|
Picture #20: One camera bag, two cameras
Small: 600x823, 130,906 bytes (128K), (html file)
Large: 1536x2048, 2,682,031 bytes (2.6M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/3.1, ISO 100, flash, 1/60 sec, 8.5mm, Superfine, center weight metering, image stabilization
35mm equivalent focal length 55.0mm
Taken by Michael Meissner on June 07, 2006 10:13:31
Last modified on June 26, 2006 at 20:22
In my Quantarray QBL bag, I have:
- Olympus E-1 with 14-54mm lens attached
- Olympus C-2100UZ camera
- 11-22mm lens (underneath C-2100Uz)
- 50mm lens (underneat E-1)
- 50-200mm lens with EC-14 teleconverter
- FL-50 flash with Flip-It flash modifier
- Promaster 5750DX flash with attachment for C-2100UZ
- Both compact flash and smartmedia memory cards
- Batteries for both cameras
- Miscellaneous other gear
|
Picture #21: National Geographic NG-2475 bag
Small: 600x846, 115,678 bytes (113K), (html file)
Large: 1536x2048, 2,932,069 bytes (2.8M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias 0.7, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:32:25
Last modified on August 13, 2006 at 12:04
E-1 with 14-54mm attached in main side, 50-200mm with E-14 attached in left
lens compartment, 50mm macro and 11-22mm lenses in right lens compartment.
|
Picture #22: National Geographic NG-2475 bag #2
Small: 600x846, 74,554 bytes (73K), (html file)
Large: 1200x1600, 1,806,434 bytes (1.7M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:33:33
Last modified on August 13, 2006 at 12:04
Inner cover, partially zipped.
|
Picture #23: National Geographic NG-2475 bag top view
Small: 800x623, 99,288 bytes (97K), (html file)
Large: 2048x1536, 2,858,579 bytes (2.7M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:34:13
Last modified on August 13, 2006 at 12:04
|
Picture #24: National Geographic NG-2475 bag partially closed
Small: 800x623, 71,766 bytes (71K), (html file)
Large: 2048x1536, 2,642,638 bytes (2.5M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias -0.3, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:34:53
Last modified on August 13, 2006 at 12:04
|
Picture #25: National Geographic NG-2475 bag top view #2
Small: 800x623, 82,688 bytes (81K), (html file)
Large: 2048x1536, 2,672,827 bytes (2.5M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias -0.3, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:35:53
Last modified on August 13, 2006 at 12:04
|
Picture #26: National Geographic NG-2475 bag #3
Small: 800x623, 103,396 bytes (101K), (html file)
Large: 2048x1536, 2,819,574 bytes (2.7M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias -0.3, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:37:23
Last modified on August 13, 2006 at 12:04
E-1 with 50-200mm + EC-14 teleconverter attached, 14-54mm + EX-25 in left lens
pocket, 11-22mm + 50mm lenses in right lens pocket.
|
Picture #27: Adorama Slinger
Small: 800x623, 80,209 bytes (79K), (html file)
Large: 2048x1536, 1,388,630 bytes (1.3M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias 0.7, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:40:21
Last modified on August 13, 2006 at 12:04
E-1 with 50-200mm with EC-14 teleconverter on right side. 11-22mm lens in the
middle. 14-54mm and 50mm lens on the left side. FL-50 in the front pocket.
|
Picture #28: Adorama Slinger with contents outside
Small: 800x623, 79,426 bytes (78K), (html file)
Large: 2048x1536, 2,571,689 bytes (2.5M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias 0.7, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:40:53
Last modified on August 13, 2006 at 21:35
E-1 with 50-200mm with EC-14 teleconverter on right side. 11-22mm lens in the
middle. 14-54mm and 50mm lens on the left side. FL-50 in the front pocket.
|
Picture #29: Adorama slinger
Small: 800x623, 92,119 bytes (90K), (html file)
Large: 1600x1200, 2,006,995 bytes (1.9M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias 0.7, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 11:41:56
Last modified on August 13, 2006 at 12:04
E-1 with 14-54mm lens attached on the right side with 50mm lens underneath it.
11-22mm lens in the middle. 50-200mm lens with EC-14 teleconverter on the left
side. FL-50 flash in the front pocket.
|
Picture #30: Adorama Slinger with contents outside #2
Small: 800x623, 59,849 bytes (59K), (html file)
Large: 2048x1536, 1,178,915 bytes (1.1M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.9mm, Superfine, center weight metering, bias 0.7, image stabilization
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on August 13, 2006 11:42:37
Last modified on August 13, 2006 at 21:42
E-1 with 14-54mm lens attached on the right side with 50mm lens underneath it.
11-22mm lens in the middle. 50-200mm lens with EC-14 teleconverter on the left
side. FL-50 flash in the front pocket.
|
Picture #31: National Geographic NG-2475 with side attachments
Small: 800x623, 88,508 bytes (87K), (html file)
Large: 1600x1200, 1,311,092 bytes (1.3M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/40 sec, 8.4mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 47.0mm
Taken by Michael Meissner on August 15, 2006 07:58:13
Last modified on August 15, 2006 at 08:01
|
Picture #32: National Geographic NG-2475 inner flap rolled up
Small: 600x846, 85,483 bytes (84K), (html file)
Large: 1536x2048, 2,114,854 bytes (2.0M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Canon S1 camera
f/5.6, ISO 50, flash, 1/60 sec, 5.8mm, Superfine, center weight metering, bias -0.3, image stabilization
35mm equivalent focal length 38.0mm
Taken by Michael Meissner on August 13, 2006 13:07:25
Last modified on August 18, 2006 at 22:59
|
Picture #33: National Geographic NG-5162 backpack
Small: 800x623, 73,402 bytes (72K), (html file)
Large: 1600x1200, 1,132,360 bytes (1.1M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/60 sec, 13.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 72.0mm
Taken by Michael Meissner on February 13, 2007 09:05:40
Last modified on February 13, 2007 at 09:05
- Top divider has 14-54mm lens, 11-22mm lens, EX-25 teleconverter.
- Middle divider has E-1 camera with SHLD-2 portrait grip, EC-14 teleconverter, and 50-200mm lens attached.
- Bottom divider has FL-50 flash.
|
Picture #34: National Geographic NG-5162 backpack #2
Small: 800x623, 72,208 bytes (71K), (html file)
Large: 1600x1200, 1,173,504 bytes (1.1M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 11.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 61.0mm
Taken by Michael Meissner on February 13, 2007 09:06:24
Last modified on February 13, 2007 at 09:06
Bag has all of the gear shown in the previous picture in the bottom compartment.
|
Picture #35: National Geographic NG-5162 backpack #3
Small: 800x623, 73,986 bytes (73K), (html file)
Large: 1600x1200, 1,167,102 bytes (1.1M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/40 sec, 8.4mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 47.0mm
Taken by Michael Meissner on February 13, 2007 09:07:27
Last modified on February 13, 2007 at 09:07
This shows the laptop compartment. It is too small (13x9.5") to hold my laptops.
|
Picture #36: National Geographic NG-5162 backpack #4
Small: 600x846, 62,182 bytes (61K), (html file)
Large: 1200x1600, 1,457,392 bytes (1.4M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 11.3mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 63.0mm
Programs used: rotate
Taken by Michael Meissner on February 13, 2007 09:10:12
Last modified on February 13, 2007 at 09:10
This shows the top compartment, and the two side bags suitable to hold a water bottle.
|
Picture #37: National Geographic NG-5162 backpack #5
Small: 600x846, 69,190 bytes (68K), (html file)
Large: 1200x1600, 1,525,047 bytes (1.5M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 9.9mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 55.0mm
Programs used: rotate
Taken by Michael Meissner on February 13, 2007 09:13:15
Last modified on February 13, 2007 at 09:13
This shows the dividers in the bottom section without any camera gear in it.
|
Picture #38: National Geographic NG-2475 shoulder bag & NG-5162 backpack
Small: 800x623, 71,977 bytes (71K), (html file)
Large: 1600x1200, 1,134,720 bytes (1.1M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 9.9mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 55.0mm
Taken by Michael Meissner on February 13, 2007 09:17:50
Last modified on February 13, 2007 at 09:17
National Geographic NG-2475 medium shoulder bag fully loaded on the left,
National Geographic NG-5162 medium backpack on the right.
|
Picture #39: National Geographic NG-2475 folded up
Small: 640x526, 52,921 bytes (52K), (html file)
Large: 2560x1920, 3,512,668 bytes (3.3M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/2.0, ISO 100, FL-50 flash, 1/100 sec, 50.0mm, auto mode, SHQ, matrix metering, +2 sharpening
35mm equivalent focal length 100.0mm
Taken by Michael Meissner on February 13, 2007 14:57:15
Last modified on February 13, 2007 at 14:57
The lens in front of the bag is the Olympus 14-54mm lens for comparison. The
lens bag in the back can be squished for better packing.
|
Picture #40: National Geographic NG-2475 bag #4
Small: 600x846, 63,915 bytes (63K), (html file)
Large: 1200x1600, 1,471,680 bytes (1.4M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/60 sec, 13.8mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 77.0mm
Programs used: rotate
Taken by Michael Meissner on February 14, 2007 10:22:12
Last modified on February 14, 2007 at 10:22
|
Picture #41: Adorama Slinger bag
Small: 600x823, 75,844 bytes (75K), (html file)
Large: 1536x2048, 2,177,891 bytes (2.1M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Canon S1 camera
f/2.8, ISO 100, flash, 1/60 sec, 8.3mm, Superfine, Evaluative, no image stabilization
35mm equivalent focal length 55.0mm
Programs used: rotate
Taken by Michael Meissner on February 23, 2007 08:40:08
Last modified on February 23, 2007 at 08:40
|
Picture #42: Camera bags
Small: 1000x523, 93,181 bytes (91K), (html file)
Large: 2000x1000, 2,135,216 bytes (2.0M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Canon S1 camera
f/2.8, ISO 100, flash, 1/60 sec, 6.9mm, Superfine, Evaluative, no image stabilization
35mm equivalent focal length 45.0mm
Programs used: gimp
Taken by Michael Meissner on February 23, 2007 08:41:16
Last modified on February 23, 2007 at 09:16
|
Picture #43: Too many bags
Small: 816x635, 104,693 bytes (103K), (html file)
Large: 3264x2448, 3,668,758 bytes (3.5M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-8080WZ camera
f/2.8, ISO 50, flash, 1/50 sec, 12.1mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 48.0mm
Taken by Michael Meissner on November 24, 2007 21:23:55
Last modified on November 24, 2007 at 20:23
|
Picture #44: Too many bags #2
Small: 816x635, 96,382 bytes (95K), (html file)
Large: 3264x2448, 3,756,711 bytes (3.6M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-8080WZ camera
f/2.5, ISO 50, flash, 1/50 sec, 11.9mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 47.0mm
Taken by Michael Meissner on November 24, 2007 21:24:20
Last modified on November 24, 2007 at 20:24
|
Picture #45: National Geographic NG-2475 camera bag
Small: 912x707, 167,327 bytes (164K), (html file)
Large: 3648x2736, 9,136,874 bytes (8.7M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-3 camera with Olympus 12-60mm SWD f/2.8-4.0 lens
f/8.0, ISO 100, FL-50R flash, 1/60 sec, 27.0mm, aperture priority, natural color, SHQ, matrix metering, auto + manual focus, image stabilization, noise reduction
35mm equivalent focal length 54.0mm
Extra equipment used: Olympus FL-50R flash
Programs used: gimp
Taken by Michael Meissner on April 25, 2008 09:36:48
Last modified on April 25, 2008 at 09:43
Camera bag is organized as follows:
- Left camera: Olympus E-510 with 50-200mm lens + EC-14 mounted.
- Left lens pouch: Sigma 70-210mm manual lens + 2x extender.
- Right lens pouch: 11-22mm lens, 50mm lens.
- Right camera: Olympus E-1 with 14-54mm lens mounted.
- Left front pocket: Extra batteries, memory cards, and filter cleaning cloth.
- Right front pocket: FL-50 flash, FL-36 flash, Demb Flip-it junior, Demb diffuser.
- Left top pocket: 67mm expocap, 67mm polarizer.
- Right top pocket: RM-CB1, RM-UC1 clone, hand straps.
|
Picture #46: Lowepro Omnisport with E-3, 14-54mm, 50-200mm, FL-36
Small: 800x623, 126,309 bytes (124K), (html file)
Large: 2400x1800, 4,470,164 bytes (4.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-1 camera with Sigma 30mm f/1.4 lens
f/5.6, ISO 100, FL-50 flash, 1/60 sec, 30.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 60.0mm
Extra equipment used: FL-50 flash
Programs used: gimp
Taken by Michael Meissner on April 23, 2009 09:47:48
Last modified on April 23, 2009 at 10:05
|
Picture #47: Lowepro Omnisport with E-3, 14-54mm, 50-200mm, FL-36 #2
Small: 800x623, 156,593 bytes (153K), (html file)
Large: 2400x1800, 5,546,253 bytes (5.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-1 camera with Sigma 30mm f/1.4 lens
f/5.6, ISO 100, FL-50 flash, 1/60 sec, 30.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 60.0mm
Extra equipment used: FL-50 flash
Programs used: gimp
Taken by Michael Meissner on April 23, 2009 09:48:44
Last modified on April 23, 2009 at 10:06
|
Picture #48: Lowepro Omnisport with E-3, 14-54mm, 50-200mm, FL-36 #3
Small: 800x623, 137,402 bytes (135K), (html file)
Large: 2400x1800, 5,094,196 bytes (4.9M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-1 camera with Sigma 30mm f/1.4 lens
f/5.6, ISO 100, FL-50 flash, 1/60 sec, 30.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 60.0mm
Extra equipment used: FL-50 flash
Programs used: gimp
Taken by Michael Meissner on April 23, 2009 09:49:24
Last modified on April 23, 2009 at 10:08
|
Picture #49: Traveling container for E-P2 and lenses
Small: 750x1023, 140,305 bytes (138K), (html file)
Large: 3000x4000, 7,018,213 bytes (6.7M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, flash (+0.3 flash compensation), 1/60 sec, 22.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 44.0mm
Extra equipment used: pop-up flash
Programs used: crop, raw therapee, rotate
Taken by Michael Meissner on July 16, 2012 08:19:22
Last modified on July 16, 2012 at 08:43
|
Picture #50: Traveling container for E-P2 and lenses #2
Small: 600x846, 85,518 bytes (84K), (html file)
Large: 2400x3200, 6,636,805 bytes (6.3M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, flash (+0.3 flash compensation), 1/60 sec, 22.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 44.0mm
Extra equipment used: pop-up flash
Programs used: gimp
Taken by Michael Meissner on July 16, 2012 08:21:28
Last modified on July 16, 2012 at 08:48
|
Picture #51: Tullio backpack loaded
Small: 900x698, 155,060 bytes (152K), (html file)
Large: 3600x2700, 3,158,630 bytes (3.0M), (html file)
Copyright, Michael Meissner 2024, All rights reserved
Olympus Stylus-1 camera
f/2.8, ISO 400, flash, 1/30 sec, 6.0mm, auto mode, vivid color, SHQ, matrix metering, image stabilization (mode 4), noise reduction auto
35mm equivalent focal length 28.0mm
Programs used: crop, raw therapee
Taken by Michael Meissner on October 13, 2024 01:18:31
Last modified on October 13, 2024 at 01:50
Tulio backpack includes:
- OM OM-1 mark I camera with Olympus 12-200mm f/3.5-6.3 lens mounted
- Olympus E-m5 mark III with Olympus 7-14mm f/2.8 lens mounted
- Olympus 12-40mm f/2.8 mark I lens
- Olympus 40-150mm f/2.8 lens with tripod mount
- Olympus 100-400mm f/5-6.3 lens with tripod mount
- Olympus MC-20 tele-extender
- Olympus 17mm f/1.2 lens
- 2 extra BLX-1 batteries
- 2 extra BLS-50 batteries
- RM-WR1 wireless/wired shutter release
- Tripod
- Weighs 21.5 pounds (9.75 kg)
|
Picture #52: Tullio backpack loaded #2
Small: 900x698, 170,467 bytes (167K), (html file)
Large: 3600x2700, 10,832,154 bytes (11M), (html file)
Olympus Stylus-1 camera
f/2.8, ISO 400, flash, 1/30 sec, 6.0mm, auto mode, vivid color, SHQ, matrix metering, image stabilization (mode 4), noise reduction auto
35mm equivalent focal length 28.0mm
Programs used: crop, gimp, raw therapee, rawtherapee-helper
Taken by Michael Meissner on October 13, 2024 01:19:38
Last modified on October 13, 2024 at 02:58
|
Picture #53: Tullio backpack with tripod
Small: 675x923, 186,946 bytes (183K), (html file)
Large: 2700x3600, 7,126,144 bytes (6.8M), (html file)
Copyright, Michael Meissner 2024, All rights reserved
Olympus Stylus-1 camera
f/2.8, ISO 400, flash, 1/30 sec, 6.0mm, auto mode, vivid color, SHQ, matrix metering, image stabilization (mode 4), noise reduction auto
35mm equivalent focal length 28.0mm
Programs used: crop, raw therapee, rotate
Taken by Michael Meissner on October 13, 2024 01:20:28
Last modified on October 13, 2024 at 02:15
|
I originally bought a small tabletop tripod from Walmart, but discovered that
it wasn't heavy enough to hold the C-2100UZ, let along the camera plus flash
bracket without flipping. After seeing some positive reviews about it, I went
out and got an Ultrapod II tripod. It is sturdy enough to hold the
camera in the horizontal position (but not the vertical position). In
addition, it has a velcro strap permanently attached, so that you can lash the
tripod to a tree or such. The velcro strap makes it handy to attach to my
camera bag as shown.
One of the issues C-2100UZ have with the design of the camera is that Olympus
put in plastic screw threads. After discussion in the
dpreview Olympus
forum, for my first attempt, I looked around and found a spacer bar that
attaches to the screw thread and then provides a metal screw hole to attach the
tripod or flash bracket to. It is small enough that it won't block the battery
component.
I was browsing in the local Microcenter, and noticed the Sima SVR quick release
was rather small. It does not block the battery compartment, and now has
replaced the spacer bar on my camera. It allows me to keep the camera in the
Stroboflip camera bracket all of the time and use the quick release mechanism
to change batteries. I bought a second quick release adapter for use on the
tripods (particularly the Ultrapod, which doesn't have a quick release
mechanism).
I went to a local craft/sewing store and bought a cardboard backdrop used for
science projects and got fabric that is two sided (dark, velvet like on one
side, and light on the other) to use for backgrounds in doing shots of things
like flowers, etc. I need to iron it to get the wrinkles from the folds out.
During the winter we have two bird feeders next to the house, and I always like
to try and take pictures of the birds. However, the birds sometimes get
spooked if I'm sitting there with the camera up to my eye waiting for the shot.
So I experimented with mounting the camera on a Promaster 6300 tripod with a
Stroboframe Vertaflip PHD Bracket on top of the tripod so the camera is
balanced. In order to prevent the camera from going to sleep, I use a
digipower DPS-9000 battery that mimics the external AC adaptor. I hook up the
camera via the USB connection, and use
gphoto2 under Linux to fire the camera and
later download the pictures.
Picture #1: Vivitar VP1200 tripod
Small: 600x823, 64,772 bytes (64K), (html file)
Large: 1200x1600, 1,213,371 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 8.4mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 47.0mm
Taken by Michael Meissner on June 08, 2002 03:12:04
Last modified on June 08, 2002 at 21:02
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #2: Spacer bar to protect the screw threads
Small: 800x623, 76,963 bytes (76K), (html file)
Large: 1600x1200, 1,328,470 bytes (1.3M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/8.0, ISO 100, flash, 1/60 sec, 13.8mm, auto mode, SHQ, matrix metering, macro
35mm equivalent focal length 77.0mm
Taken by Michael Meissner on June 23, 2002 23:50:09
Last modified on June 24, 2002 at 09:52
|
Picture #3: Ultrapod-II table top tripod
Small: 800x623, 111,905 bytes (110K), (html file)
Large: 1600x1200, 1,589,905 bytes (1.5M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 100, 1/125 sec, 11.6mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 64.0mm
Taken by Michael Meissner on July 20, 2002 01:24:32
Last modified on July 20, 2002 at 11:39
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #4: Sima SVR quick release platform
Small: 800x623, 67,934 bytes (67K), (html file)
Large: 1600x1200, 1,238,496 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 11.3mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 63.0mm
Taken by Michael Meissner on July 20, 2002 01:56:44
Last modified on July 20, 2002 at 11:53
|
Picture #5: Sima SVR quick release platform #2
Small: 600x846, 74,665 bytes (73K), (html file)
Large: 1200x1600, 1,248,278 bytes (1.2M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus D-510Z camera
f/2.8, ISO 100, flash, 1/30 sec, 5.6mm, auto mode, SHQ, spot metering
35mm equivalent focal length 37.0mm
Taken by Michael Meissner on July 20, 2002 01:58:58
Last modified on July 20, 2002 at 11:58
|
Picture #6: Ultrapod-II attached to my camera bag
Small: 800x623, 83,769 bytes (82K), (html file)
Large: 1600x1200, 1,483,152 bytes (1.4M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/5.6, ISO 400, 1/125 sec, 11.0mm, manual mode, SHQ, matrix metering
35mm equivalent focal length 61.0mm
Taken by Michael Meissner on August 13, 2002 12:13:39
Last modified on August 13, 2002 at 16:20
Shutter speed of 1/125 or 1/250 may indicate use of flash
|
Picture #7: In progress work of new camera base to center the tripod screw hole over the lens
Small: 600x846, 82,845 bytes (81K), (html file)
Large: 1200x1600, 1,108,406 bytes (1.1M), (html file)
Copyright, Michael Meissner 2002, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/40 sec, 9.4mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 52.0mm
Taken by Michael Meissner on September 03, 2002 23:35:39
Last modified on September 04, 2002 at 23:15
|
Picture #8: Promaster 6300 tripod
Small: 600x823, 79,545 bytes (78K), (html file)
Large: 1200x1600, 1,253,292 bytes (1.2M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/40 sec, 8.8mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 49.0mm
Taken by Michael Meissner on January 14, 2003 21:24:22
Last modified on January 14, 2003 at 21:40
|
Picture #9: Backdrop for studio type shots
Small: 565x646, 57,806 bytes (57K), (html file)
Large: 1130x1200, 984,144 bytes (962K), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, 1/30 sec, 7.0mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 39.0mm
Taken by Michael Meissner on January 14, 2003 21:24:53
Last modified on January 14, 2003 at 21:49
|
Picture #10: Closeup of Sima QuicKonnect
Small: 800x623, 104,501 bytes (103K), (html file)
Large: 1600x1200, 1,277,228 bytes (1.2M), (html file)
Copyright, Michael Meissner 2003, All rights reserved
Olympus C-2100UZ camera
f/8.0, ISO 200, flash, 1/80 sec, 17.3mm, aperture priority, SHQ, matrix metering, macro
35mm equivalent focal length 96.0mm
Taken by Michael Meissner on August 29, 2003 10:28:28
Last modified on August 29, 2003 at 10:37
|
Picture #11: Camera setup for taking bird pictures via USB remote control
Small: 599x846, 66,168 bytes (65K), (html file)
Large: 1712x2288, 1,842,528 bytes (1.8M), (html file)
Copyright, Michael Meissner 2004, All rights reserved
Olympus D-40Z camera
f/4.8, ISO 100, flash, 1/100 sec, 19.4mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 95.0mm
Taken by Michael Meissner on December 30, 2004 11:02:11
Last modified on December 30, 2004 at 12:29
|
Picture #12: Camera setup for taking bird pictures via USB remote control #2
Small: 599x846, 92,631 bytes (91K), (html file)
Large: 1712x2288, 2,103,820 bytes (2.0M), (html file)
Copyright, Michael Meissner 2004, All rights reserved
Olympus D-40Z camera
f/2.8, ISO 100, flash, 1/40 sec, 9.2mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 45.0mm
Taken by Michael Meissner on December 30, 2004 11:02:32
Last modified on December 30, 2004 at 12:29
|
Picture #13: Fourth of July fireworks setup
Small: 768x599, 85,623 bytes (84K), (html file)
Large: 3072x2304, 4,376,645 bytes (4.2M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus SP-550UZ camera
f/3.2, ISO 64, 1/40 sec, 6.4mm, auto mode, HQ, matrix metering
35mm equivalent focal length 39.0mm
Programs used: gimp
Taken by Michael Meissner on July 05, 2008 20:07:13
Last modified on July 06, 2008 at 00:09
|
Picture #14: Acratech leveling base with 3/8" screw thread
Small: 800x623, 86,173 bytes (85K), (html file)
Large: 2400x1800, 3,726,123 bytes (3.6M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 32.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 64.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:34:02
Last modified on September 16, 2009 at 09:19
Product link
|
Picture #15: E-1/50mm + Acratech leveling base + Manfrotto 234RC
Small: 800x623, 92,424 bytes (91K), (html file)
Large: 3200x2400, 6,639,066 bytes (6.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 200, FL-36 flash, 1/60 sec, 28.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 56.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:35:47
Last modified on September 16, 2009 at 09:25
|
Picture #16: Trek-tek magnetic ballhead
Small: 800x623, 66,527 bytes (65K), (html file)
Large: 2400x1800, 3,499,257 bytes (3.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/80 sec, 38.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 76.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:37:04
Last modified on September 16, 2009 at 09:30
|
Picture #17: Trek-tek magnetic ballhead #2
Small: 800x623, 91,571 bytes (90K), (html file)
Large: 2400x1800, 4,032,474 bytes (3.8M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/80 sec, 41.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 82.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:44:23
Last modified on September 16, 2009 at 09:31
|
Picture #18: Manfrotto 680B monopod + Manfrotto 678 folding base
Small: 800x423, 64,894 bytes (64K), (html file)
Large: 3200x1600, 4,024,127 bytes (3.8M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 250, FL-36 flash, 1/60 sec, 17.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 34.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:52:11
Last modified on September 16, 2009 at 09:37
|
Picture #19: Manfrotto 680B monopod + Manfrotto 678 folding base #2
Small: 400x846, 37,958 bytes (38K), (html file)
Large: 1600x3200, 3,965,180 bytes (3.8M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 14.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 28.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:53:44
Last modified on September 16, 2009 at 09:43
|
Picture #20: E-1/50mm + Manfrotto 680B monopod
Small: 800x623, 69,283 bytes (68K), (html file)
Large: 2400x1800, 3,155,139 bytes (3.0M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 14.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 28.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:57:03
Last modified on September 16, 2009 at 09:45
|
Picture #21: E-1/50mm + Manfrotto 680B monopod #2
Small: 400x846, 45,436 bytes (45K), (html file)
Large: 1600x3200, 4,413,372 bytes (4.2M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 14.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 28.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 08:57:53
Last modified on September 16, 2009 at 09:47
|
Picture #22: Manfrotto 680B monopod + Manfrotto 678 folding base #3
Small: 800x423, 74,506 bytes (73K), (html file)
Large: 3200x1600, 4,819,214 bytes (4.6M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 14.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 28.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 16, 2009 09:01:11
Last modified on September 16, 2009 at 09:49
|
Picture #23: Manfrotto 790B monopod
Small: 800x423, 72,839 bytes (72K), (html file)
Large: 3200x1600, 4,989,778 bytes (4.8M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 19.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 38.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 17, 2009 08:09:23
Last modified on September 17, 2009 at 08:53
Manfrotto 790B Modo product link
|
Picture #24: Manfrotto 790B monopod + Trek-tek magnetic ballhead
Small: 800x423, 72,948 bytes (72K), (html file)
Large: 3200x1600, 5,108,993 bytes (4.9M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 14.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 28.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 17, 2009 08:10:03
Last modified on September 17, 2009 at 08:58
|
Picture #25: E-510 on top of Manfrotto 790B monopod
Small: 600x846, 78,137 bytes (77K), (html file)
Large: 2400x3200, 6,488,156 bytes (6.2M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/80 sec, 42.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 84.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 17, 2009 08:13:17
Last modified on September 17, 2009 at 09:00
|
Picture #26: Manfrotto 790B monopod + Trek-tek magnetic ballhead #2
Small: 900x248, 42,683 bytes (42K), (html file)
Large: 3600x900, 2,780,092 bytes (2.7M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-36 flash, 1/60 sec, 17.0mm, aperture priority, natural color, auto gradation, SHQ, matrix metering, image stabilization, noise filter low
35mm equivalent focal length 34.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 17, 2009 08:15:11
Last modified on September 17, 2009 at 09:02
|
Picture #27: Mechanical shutter release
Small: 800x423, 84,559 bytes (83K), (html file)
Large: 3200x1600, 4,736,979 bytes (4.5M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 500, FL-36 flash, 1/60 sec, 27.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 54.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on August 25, 2010 09:57:24
Last modified on August 25, 2010 at 10:29
|
Picture #28: Mechanical shutter release #2
Small: 800x623, 90,587 bytes (89K), (html file)
Large: 3200x2400, 6,237,060 bytes (5.9M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 500, FL-36 flash, 1/80 sec, 38.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 76.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on August 25, 2010 10:02:20
Last modified on August 25, 2010 at 10:33
|
Picture #29: Mechanical shutter release #3
Small: 800x623, 77,850 bytes (77K), (html file)
Large: 3200x2400, 6,537,767 bytes (6.2M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 640, FL-36 flash, 1/100 sec, 52.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 104.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on August 25, 2010 10:02:46
Last modified on August 25, 2010 at 10:38
|
Picture #30: Mechanical shutter release #4
Small: 800x556, 86,380 bytes (85K), (html file)
Large: 2400x1600, 3,412,656 bytes (3.3M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 1000, FL-36 flash, 1/80 sec, 44.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 88.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on August 25, 2010 10:10:23
Last modified on August 25, 2010 at 10:45
|
Picture #31: Need more Camera Capture Clips
Small: 1000x773, 168,056 bytes (165K), (html file)
Large: 4000x3000, 4,787,130 bytes (4.6M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm-IIR f/3.5-5.6 lens
f/8.0, ISO 250, Metz 48 flash (+0.33 flash compensation), 1/60 sec, 15.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 30.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, raw therapee
Taken by Michael Meissner on July 18, 2013 09:00:49
Last modified on July 18, 2013 at 09:07
|
Picture #32: Bogen 3040 I owned briefly
Small: 667x1023, 270,406 bytes (265K), (html file)
Large: 2000x3000, 2,780,876 bytes (2.7M), (html file)
Copyright, Michael Meissner 2016, All rights reserved
Olympus E-M1-I camera with Olympus-m43 12-40mm f/2.8 lens
f/4.5, ISO 200, 1/200 sec, 19.0mm, auto mode, vivid color, SHQ, matrix metering, image stabilization (mode 4), noise filter low
35mm equivalent focal length 38.0mm
Programs used: crop, raw therapee, rotate left
Taken by Michael Meissner on November 07, 2016 13:02:42
Last modified on November 08, 2016 at 00:14
I picked this tripod (Bogen 3040) at a photo show.
I was hoping to use it for shooting video at the renaissance faires by mounting the camera over the crowds heads.
However, in practice, the tripod is too heavy to carry around, and I'm giving it to G. W. Smith.
|
Picture #33: Bogen 3040 I owned briefly #2
Small: 690x943, 141,082 bytes (138K), (html file)
Large: 3450x4600, 2,906,528 bytes (2.8M), (html file)
Copyright, Michael Meissner 2016, All rights reserved
Olympus E-M1-I camera with Olympus-m43 12-40mm f/2.8 lens
f/5.0, ISO 200, 1/400 sec, 34.0mm, auto mode, vivid color, SHQ, matrix metering, bias -0.3, digital zoom x2, image stabilization (mode 4), noise filter low
35mm equivalent focal length 136.0mm, digital zoom x2
Programs used: crop, raw therapee, rotate left
Taken by Michael Meissner on November 07, 2016 13:04:04
Last modified on November 08, 2016 at 00:17
I picked this tripod (Bogen 3040) at a photo show.
I was hoping to use it for shooting video at the renaissance faires by mounting the camera over the crowds heads.
However, in practice, the tripod is too heavy to carry around, and I'm giving it to G. W. Smith.
|
Picture #34: Broken tripod
Small: 900x822, 215,779 bytes (211K), (html file)
Large: 3600x3200, 12,068,459 bytes (12M), (html file)
Copyright, Michael Meissner 2017, All rights reserved
Olympus E-M1-I camera with Olympus-m43 12-40mm f/2.8 lens
f/2.8, ISO 320, flash (+0.33 flash compensation), 1/60 sec, 34.0mm, auto mode, vivid color, SHQ, flash (5500K), matrix metering, image stabilization (mode 4), noise filter low
35mm equivalent focal length 68.0mm
Programs used: crop, gimp
Taken by Michael Meissner on July 11, 2017 08:39:32
Last modified on July 11, 2017 at 09:24
|
I bought an Olympus A-200 lens that has 49mm screw threads (same as the
C-2100UZ) and provides 1.5x magnification. This provides the equivalent of a
570mm lens on a conventional 35mm camera. I find I can get roughly 1/2 of the
zoom range of the C-2100UZ without seeing vignetting. The A-200 lens was made
for a different Olympus camera line, and was usually sold out. The New York
photo store B&H got in a shipment
of these lenses, and was sold out within a day, including the one I bought.
The lens does not have screw threads on the outside, but it is roughly 72mm, so
I attached a 72mm UV filter for lens protection with velcro. I am not entirely
happy with this setup, and will probably redo it with duct tape. When I bought
the lens, I also bought a 72mm lens hood, and a 72mm polarizer.
Picture #1: E1 camera with lenses.
Small: 800x623, 54,539 bytes (54K), (html file)
Large: 1600x1200, 874,491 bytes (854K), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus C-2100UZ camera
f/4.5, ISO 100, 1/250 sec, 8.2mm, manual mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 46.0mm
Extra equipment used: Promaster 5750DX flash
Taken by Michael Meissner on January 23, 2005 21:21:51
Last modified on August 28, 2005 at 11:54
All three lenses are extended to their telephoto position, and the lens hood
for the lens is in front of it. The lens on the left is a Sigma 55-200mm lens
(f/4 - f/5.6). The lens on the camera is an Olympus 14-54 lens (f/2.8 -
f/3.5). The lens on the left is a Sigma 18-125 lens (f/3.5 - f/5.6).
|
Picture #2: 4/3rds and OM mount lenses
Small: 640x503, 42,581 bytes (42K), (html file)
Large: 2560x1920, 4,950,273 bytes (4.7M), (html file)
Copyright, Michael Meissner 2005, All rights reserved
Olympus E-1 camera
ISO 100, ext. flash, 1/160 sec, manual mode, SHQ, matrix metering, -2 contrast, +2 sharpening
35mm equivalent focal length 0.0mm
Extra equipment used: Promaster 5750DX flash, Olympus OM 50mm lens
Taken by Michael Meissner on June 27, 2005 01:12:09
Last modified on August 28, 2005 at 11:54
On the back row,
Vivitar 100-300mm (f/5, 62mm),
Vivitar 70-210mm (f/2.8-4, 62mm), and
Sigma 55-200mm (f/4.5-5.6 55mm).
On the middle row,
Olympus 14-54mm (f/2.8-3.5, 67mm), and
Sigma 18-125mm (f/3.5-5.6 62mm).
On the front row,
Olympus 50mm macro (f/2, 52mm).
|
Picture #3: Broken E-1 eyepiece
Small: 800x623, 140,666 bytes (138K), (html file)
Large: 1600x1200, 2,391,452 bytes (2.3M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/100 sec, 20.7mm, auto mode, SHQ, cloudy, matrix metering, macro
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on June 20, 2006 23:07:26
Last modified on June 20, 2006 at 23:12
On June 20th, 2006, the sunset sky was really neat, and I was on my way home
from picking up Chinese food, so I stopped at the Spectacle Pond boat ramp to
try and get some pictures. By the time I got there, it was really too dark to
take pictures, and I was climing up the hill to the car, and tripped. The E-1
went flying out of my hands and landed on the ground. It looks like the only
thing affected is a broken eyepiece and a scuffed up screen protector. The
camera and lens seem to still take decent pictures, but I will send it in to
Olympus for service.
|
Picture #4: Broken E-1 eyepiece #2
Small: 800x623, 93,242 bytes (92K), (html file)
Large: 1600x1200, 1,309,518 bytes (1.2M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/100 sec, 20.7mm, auto mode, SHQ, cloudy, matrix metering, macro
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on June 20, 2006 23:10:19
Last modified on June 20, 2006 at 23:12
|
Picture #5: Broken E-1 eyepiece #3
Small: 800x623, 104,978 bytes (103K), (html file)
Large: 1600x1200, 1,211,397 bytes (1.2M), (html file)
Copyright, Michael Meissner 2006, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/100 sec, 20.7mm, auto mode, SHQ, cloudy, matrix metering, macro
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on June 20, 2006 23:10:36
Last modified on June 20, 2006 at 23:12
|
Picture #6: E-1 with 18-125mm lens mounted, 14-54mm next to it
Small: 800x623, 86,712 bytes (85K), (html file)
Large: 1600x1200, 1,215,510 bytes (1.2M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/60 sec, 16.2mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 90.0mm
Taken by Michael Meissner on April 09, 2007 22:55:36
Last modified on April 09, 2007 at 22:55
|
Picture #7: E-1 with 18-125mm lens mounted, 14-54mm next to it #2
Small: 800x623, 80,119 bytes (79K), (html file)
Large: 1600x1200, 1,113,154 bytes (1.1M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/100 sec, 20.7mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 115.0mm
Taken by Michael Meissner on April 09, 2007 22:56:18
Last modified on April 09, 2007 at 22:56
|
Picture #8: Sigma 18-125mm lens
Small: 800x623, 73,080 bytes (72K), (html file)
Large: 1600x1200, 1,026,140 bytes (1003K), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/125 sec, 28.5mm, auto mode, SHQ, cloudy, matrix metering, macro
35mm equivalent focal length 158.0mm
Taken by Michael Meissner on April 09, 2007 22:58:23
Last modified on April 09, 2007 at 22:58
|
Picture #9: Dinosaur camera (E-1)
Small: 800x623, 44,157 bytes (44K), (html file)
Large: 3200x2400, 5,759,193 bytes (5.5M), (html file)
Olympus C-8080WZ camera
f/5.6, ISO 50, 1/60 sec, 18.4mm, aperture priority, SHQ, matrix metering
35mm equivalent focal length 72.0mm
Extra equipment used: FL-36 flash, Demb Flip-it
Programs used: gimp
Taken by Michael Meissner on October 15, 2007 09:43:16
Last modified on October 15, 2007 at 09:43
|
Picture #10: E-1 and hat
Small: 800x623, 45,551 bytes (45K), (html file)
Large: 3200x2400, 5,720,784 bytes (5.5M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-8080WZ camera
f/5.6, ISO 50, 1/60 sec, 16.5mm, aperture priority, SHQ, matrix metering
35mm equivalent focal length 65.0mm
Extra equipment used: FL-36 flash, Demb Flip-it
Programs used: gimp
Taken by Michael Meissner on October 15, 2007 09:48:16
Last modified on October 15, 2007 at 09:48
|
Picture #11: E-1 and hat #2
Small: 800x623, 38,372 bytes (38K), (html file)
Large: 3200x2400, 5,030,870 bytes (4.8M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-8080WZ camera
f/5.6, ISO 50, 1/60 sec, 16.5mm, aperture priority, SHQ, matrix metering
35mm equivalent focal length 65.0mm
Extra equipment used: FL-36 flash, Demb Flip-it
Programs used: gimp
Taken by Michael Meissner on October 15, 2007 09:49:00
Last modified on October 15, 2007 at 09:49
|
Picture #12: How the E-1 came back from warranty repair
Small: 816x635, 53,882 bytes (53K), (html file)
Large: 3264x2448, 3,969,532 bytes (3.8M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-8080WZ camera
f/2.8, ISO 50, flash, 1/50 sec, 13.2mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 52.0mm
Programs used: gimp
Taken by Michael Meissner on November 02, 2007 16:58:10
Last modified on November 02, 2007 at 16:58
|
Picture #13: How the E-1 came back from warranty repair #2
Small: 612x862, 64,050 bytes (63K), (html file)
Large: 2448x3264, 4,818,184 bytes (4.6M), (html file)
Copyright, Michael Meissner 2007, All rights reserved
Olympus C-8080WZ camera
f/2.8, ISO 50, 1/50 sec, 13.2mm, auto mode, SHQ, matrix metering
35mm equivalent focal length 52.0mm
Extra equipment used: FL-36 flash
Programs used: gimp, rotate
Taken by Michael Meissner on November 02, 2007 17:22:19
Last modified on November 02, 2007 at 17:22
|
Picture #14: E-1 with SHLD-2 battery grip
Small: 1000x856, 77,621 bytes (76K), (html file)
Large: 3000x2500, 4,687,518 bytes (4.5M), (html file)
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-50 flash, 1/60 sec, 27.0mm, aperture priority, natural color, auto gradation, matrix metering, image stabilization
35mm equivalent focal length 54.0mm
Extra equipment used: FL-50 flash
Programs used: gimp
Taken by Michael Meissner on December 06, 2008 21:59:47
Last modified on December 06, 2008 at 22:30
|
Picture #15: E-1 with SHLD-2 battery grip #2
Small: 1000x856, 85,057 bytes (84K), (html file)
Large: 3000x2500, 5,874,624 bytes (5.6M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-50 flash, 1/60 sec, 31.0mm, aperture priority, natural color, auto gradation, matrix metering, image stabilization
35mm equivalent focal length 62.0mm
Extra equipment used: FL-50 flash
Programs used: gimp
Taken by Michael Meissner on December 06, 2008 22:00:27
Last modified on December 06, 2008 at 22:24
|
Picture #16: SHLD-2 battery grip + extra battery
Small: 1000x856, 85,598 bytes (84K), (html file)
Large: 3000x2500, 5,457,318 bytes (5.2M), (html file)
Copyright, Michael Meissner 2008, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 100, FL-50 flash, 1/60 sec, 23.0mm, aperture priority, natural color, auto gradation, matrix metering, image stabilization
35mm equivalent focal length 46.0mm
Taken by Michael Meissner on December 06, 2008 22:05:30
Last modified on December 06, 2008 at 22:26
|
Picture #1: Beauty and the Beast (E-P2 and E-3)
Small: 800x623, 109,372 bytes (107K), (html file)
Large: 2400x1800, 5,066,591 bytes (4.8M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 400, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 21:38:04
Last modified on December 06, 2009 at 09:26
|
Picture #2: E-P2 with electronic viewfinder up
Small: 800x623, 87,654 bytes (86K), (html file)
Large: 2400x1800, 4,364,871 bytes (4.2M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 400, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 21:38:48
Last modified on December 06, 2009 at 09:28
|
Picture #3: E-P2 with electronic viewfinder down
Small: 800x623, 99,599 bytes (98K), (html file)
Large: 2400x1800, 4,536,163 bytes (4.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 400, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 21:39:04
Last modified on December 06, 2009 at 09:30
|
Picture #4: The box
Small: 800x623, 56,444 bytes (56K), (html file)
Large: 3200x2400, 5,753,777 bytes (5.5M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, FL-36 flash, 1/80 sec, 42.0mm, aperture priority, natural color, matrix metering, image stabilization
35mm equivalent focal length 84.0mm
Extra equipment used: FL-36
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 22:24:11
Last modified on December 06, 2009 at 18:00
|
Picture #5: The box #2
Small: 600x823, 73,438 bytes (72K), (html file)
Large: 2400x3200, 5,018,653 bytes (4.8M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, FL-36 flash, 1/60 sec, 22.0mm, aperture priority, natural color, matrix metering, image stabilization
35mm equivalent focal length 44.0mm
Extra equipment used: FL-36
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 22:25:14
Last modified on December 06, 2009 at 18:00
|
Picture #6: E-P2 box contents
Small: 800x823, 111,167 bytes (109K), (html file)
Large: 2400x2400, 5,539,493 bytes (5.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, FL-36 flash, 1/60 sec, 28.0mm, aperture priority, natural color, matrix metering, image stabilization
35mm equivalent focal length 56.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 22:30:52
Last modified on December 06, 2009 at 18:00
|
Picture #7: E-P2 electronic view and case
Small: 800x623, 91,597 bytes (90K), (html file)
Large: 3200x2400, 6,604,362 bytes (6.3M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, FL-36 flash, 1/100 sec, 54.0mm, aperture priority, natural color, matrix metering, image stabilization
35mm equivalent focal length 108.0mm
Extra equipment used: FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 05, 2009 22:32:06
Last modified on December 06, 2009 at 18:00
|
Picture #8: Olympus E-P2, Olympus 50mm lens, Promaster ring flash
Small: 800x823, 79,337 bytes (78K), (html file)
Large: 2400x2400, 2,732,401 bytes (2.6M), (html file)
Copyright, Michael Meissner 2009, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/5.6, ISO 125, FL-36 flash, 1/60 sec, 23.0mm, aperture priority, natural color, matrix metering, image stabilization
35mm equivalent focal length 46.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 30, 2009 10:21:39
Last modified on December 30, 2009 at 09:37
|
Picture #9: E-3 vs. E-P2 viewfinders
Small: 800x423, 80,218 bytes (79K), (html file)
Large: 2400x1200, 3,357,709 bytes (3.2M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/5.6, ISO 100, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on May 26, 2010 08:33:44
Last modified on May 26, 2010 at 08:49
|
Picture #10: E-3 vs. E-P2 viewfinders #2
Small: 800x623, 76,455 bytes (75K), (html file)
Large: 2400x1800, 4,383,168 bytes (4.2M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/5.6, ISO 100, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on May 26, 2010 08:35:00
Last modified on May 26, 2010 at 08:50
|
Picture #11: E-3 vs. E-P2 viewfinders #3
Small: 800x623, 71,329 bytes (70K), (html file)
Large: 1600x1200, 1,846,848 bytes (1.8M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-1 camera with Olympus 50mm f/2.0 lens
f/5.6, ISO 100, FL-36 flash, 1/100 sec, 50.0mm, aperture priority, SHQ, matrix metering, +2 contrast, +2 sharpening
35mm equivalent focal length 100.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on May 26, 2010 08:36:11
Last modified on May 26, 2010 at 08:52
|
Picture #12: Using Wolverine MyMovie as external monitor for EP-2
Small: 800x623, 86,224 bytes (85K), (html file)
Large: 1600x1200, 1,893,839 bytes (1.8M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/250 sec, 13.0mm, shutter priority, SHQ, cloudy, matrix metering
35mm equivalent focal length 72.0mm
Extra equipment used: Pop-up flash
Programs used: gimp
Taken by Michael Meissner on June 11, 2010 09:42:27
Last modified on June 11, 2010 at 10:19
|
Picture #13: Using Wolverine MyMovie as external monitor for EP-2 #2
Small: 600x846, 92,655 bytes (91K), (html file)
Large: 1200x1600, 1,964,007 bytes (1.9M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/250 sec, 9.9mm, shutter priority, SHQ, cloudy, matrix metering
35mm equivalent focal length 55.0mm
Extra equipment used: Pop-up flash
Programs used: gimp
Taken by Michael Meissner on June 11, 2010 09:44:43
Last modified on June 11, 2010 at 10:22
|
Picture #14: Using Wolverine MyMovie as external monitor for EP-2 #3
Small: 600x846, 99,074 bytes (97K), (html file)
Large: 1200x1600, 2,058,316 bytes (2.0M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 12.3mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 68.0mm
Extra equipment used: Pop-up flash
Programs used: gimp
Taken by Michael Meissner on June 11, 2010 09:47:43
Last modified on June 11, 2010 at 10:29
|
Picture #15: E-P2 with live view, mirror, and shutter release
Small: 800x623, 61,377 bytes (60K), (html file)
Large: 3200x2400, 6,345,013 bytes (6.1M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/2.8, ISO 100, FL-36 flash, 1/60 sec, 14.0mm, auto mode, natural color, SHQ, matrix metering, image stabilization, noise reduction
35mm equivalent focal length 28.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on December 10, 2010 08:26:46
Last modified on December 10, 2010 at 08:49
|
Picture #16: E-P2 with live view, mirror, and shutter release #2
Small: 792x623, 69,621 bytes (68K), (html file)
Large: 3168x2400, 6,315,716 bytes (6.0M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/2.8, ISO 1250, 1/60 sec, 14.0mm, auto mode, natural color, SHQ, matrix metering, image stabilization, noise reduction
35mm equivalent focal length 28.0mm
Programs used: gimp
Taken by Michael Meissner on December 10, 2010 08:33:29
Last modified on December 10, 2010 at 08:54
|
Picture #17: E-P2 tripod socket measurement
Small: 800x623, 117,635 bytes (115K), (html file)
Large: 3200x2400, 7,060,580 bytes (6.7M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/100 sec, 52.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 104.0mm
Extra equipment used: pop-up flash
Programs used: raw therapee
Taken by Michael Meissner on March 30, 2011 07:50:14
Last modified on March 30, 2011 at 09:04
|
Picture #18: E-P2 tripod socket measurement #2
Small: 600x846, 111,853 bytes (110K), (html file)
Large: 2400x3200, 6,390,120 bytes (6.1M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/100 sec, 54.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 108.0mm
Extra equipment used: pop-up flash
Programs used: raw therapee
Taken by Michael Meissner on March 30, 2011 07:51:21
Last modified on March 30, 2011 at 09:04
|
Picture #19: E-P2 tripod socket measurement #3
Small: 800x623, 122,241 bytes (120K), (html file)
Large: 3200x2400, 7,048,270 bytes (6.7M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/100 sec, 54.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 108.0mm
Extra equipment used: pop-up flash
Programs used: raw therapee
Taken by Michael Meissner on March 30, 2011 07:51:54
Last modified on March 30, 2011 at 09:05
|
Picture #20: E-P2 tripod socket measurement #4
Small: 800x623, 128,709 bytes (126K), (html file)
Large: 3200x2400, 6,953,249 bytes (6.6M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 100, flash (+0.3 flash compensation), 1/100 sec, 54.0mm, aperture priority, natural color, SHQ, matrix metering, image stabilization
35mm equivalent focal length 108.0mm
Extra equipment used: pop-up flash
Programs used: raw therapee
Taken by Michael Meissner on March 30, 2011 07:52:17
Last modified on March 30, 2011 at 09:05
|
Picture #21: Phottix cable with PMP video and Zeikos shutter cable
Small: 800x623, 92,768 bytes (91K), (html file)
Large: 3200x2400, 6,687,528 bytes (6.4M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.0, ISO 200, FL-36 flash (+0.33 flash compensation), 1/60 sec, 31.0mm, auto mode, vivid color, SHQ, matrix metering, auto + manual focus, image stabilization
35mm equivalent focal length 62.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on June 29, 2011 08:27:27
Last modified on June 29, 2011 at 08:45
- The cable on the left is the video tip from my JXD i696 portable music player that takes video input;
- The middle two cables are the two parts of the Phottix Hero cable, with the left being the video signal, and the right being the shutter release;
- The left cable is the cable from my Zeikos wireless shutter release.
|
Picture #22: Phottix Hero cable and Zeikos shutter release cable
Small: 800x556, 71,811 bytes (71K), (html file)
Large: 2400x1600, 3,495,678 bytes (3.3M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.6, ISO 200, FL-36 flash (+0.33 flash compensation), 1/180 sec, 100.0mm, auto mode, vivid color, SHQ, matrix metering, auto + manual focus, image stabilization
35mm equivalent focal length 200.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on June 29, 2011 08:28:00
Last modified on June 29, 2011 at 08:50
- The cable on the left is the tip for the Phottix shutter release;
- The cable on the right is the tip for the Zeikos wireless shutter release.
|
Picture #23: Phottix cable with PMP video and Zeikos shutter cable #2
Small: 900x698, 121,122 bytes (119K), (html file)
Large: 3600x2700, 9,060,050 bytes (8.6M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash (+0.33 flash compensation), 1/60 sec, 29.0mm, aperture priority, vivid color, SHQ, matrix metering, auto + manual focus, image stabilization
35mm equivalent focal length 58.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on June 29, 2011 08:34:20
Last modified on June 29, 2011 at 08:53
- The cable on the left is the video in cable for my JXD i696 portable music player;
- The cable in the middle is the Phottix Hero cable for Olympus;
- The cable on the right is the shutter cable from my Zeikos wireless shutter release.
The video cable fits in the JXD i696, but the video portion does not line up
with the part of the tip that carries the video signal.
If I hook the E-P2 with the Phottix cable, and put in the shutter release into
my Zeikos system, the camera will start taking pictures once the first picture
is taken until I remove the cable. I suspect that the two devices have the
pins assigned differently than each other.
|
Picture #24: Phottix setup
Small: 800x623, 86,633 bytes (85K), (html file)
Large: 1600x1200, 1,116,939 bytes (1.1M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 10.2mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 57.0mm
Extra equipment used: pop-up flash
Taken by Michael Meissner on June 29, 2011 21:55:52
Last modified on June 29, 2011 at 22:03
|
Picture #25: Phottix setup #2
Small: 800x623, 87,403 bytes (86K), (html file)
Large: 1600x1200, 1,140,143 bytes (1.1M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus C-2100UZ camera
f/2.8, ISO 100, flash, 1/50 sec, 10.2mm, auto mode, SHQ, cloudy, matrix metering
35mm equivalent focal length 57.0mm
Extra equipment used: pop-up flash
Taken by Michael Meissner on June 29, 2011 21:56:01
Last modified on June 29, 2011 at 22:03
|
Picture #1: Kodak Pony Premo 5x7 large format camera
Small: 900x698, 112,361 bytes (110K), (html file)
Large: 3600x2700, 8,561,561 bytes (8.2M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 200, Promaster flash, 1/100 sec, 50.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 100.0mm
Extra equipment used: Promaster ring flash
Programs used: gimp
Taken by Michael Meissner on April 18, 2010 20:24:08
Last modified on April 18, 2010 at 20:37
|
Picture #2: Kodak Pony Premo 5x7 large format camera #2
Small: 675x923, 132,334 bytes (130K), (html file)
Large: 2700x3600, 8,606,431 bytes (8.2M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 200, Promaster flash, 1/100 sec, 50.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 100.0mm
Extra equipment used: Promaster ring flash
Programs used: gimp
Taken by Michael Meissner on April 18, 2010 20:24:28
Last modified on April 18, 2010 at 20:39
|
Picture #3: Kodak Pony Premo 5x7 large format camera #3
Small: 900x698, 104,340 bytes (102K), (html file)
Large: 3600x2700, 8,411,174 bytes (8.0M), (html file)
Olympus E-3 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 200, Promaster flash, 1/100 sec, 50.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 100.0mm
Extra equipment used: Promaster ring flash
Programs used: gimp
Taken by Michael Meissner on April 18, 2010 20:24:41
Last modified on April 18, 2010 at 20:59
|
Picture #4: Closeup of the premo lens
Small: 800x623, 91,388 bytes (90K), (html file)
Large: 3200x2400, 6,769,387 bytes (6.5M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 50mm f/2.0 lens
f/8.0, ISO 200, Promaster flash, 1/100 sec, 50.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 100.0mm
Extra equipment used: Promaster ring flash
Programs used: gimp
Taken by Michael Meissner on April 18, 2010 20:24:54
Last modified on April 18, 2010 at 20:49
|
Picture #5: Kodak Pony Premo with the lens removed
Small: 800x623, 66,943 bytes (66K), (html file)
Large: 3200x2400, 6,326,993 bytes (6.0M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 500, FL-36 flash, 1/60 sec, 22.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 44.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on April 24, 2010 06:24:50
Last modified on April 24, 2010 at 07:43
|
Picture #6: Back of the Kodak Premo Pony
Small: 800x623, 50,977 bytes (50K), (html file)
Large: 3200x2400, 3,205,278 bytes (3.1M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/3.0, ISO 2000, 1/20 sec, 22.0mm, auto mode, vivid color, matrix metering, image stabilization
35mm equivalent focal length 44.0mm
Programs used: NoiseNinja, gimp
Taken by Michael Meissner on April 24, 2010 06:26:52
Last modified on April 24, 2010 at 07:48
|
Picture #7: Kodak Pony Premo fully extended
Small: 900x698, 77,318 bytes (76K), (html file)
Large: 3600x2700, 6,374,906 bytes (6.1M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 1000, FL-36 flash, 1/60 sec, 29.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 58.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on April 24, 2010 06:30:57
Last modified on April 24, 2010 at 07:49
|
Picture #8: Kodak Pony Premo with extension bar
Small: 800x823, 84,857 bytes (83K), (html file)
Large: 2400x2400, 5,507,163 bytes (5.3M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 250, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on April 24, 2010 06:31:36
Last modified on April 24, 2010 at 07:52
|
Picture #9: Kodak Pony Premo folded into the box
Small: 800x623, 58,175 bytes (57K), (html file)
Large: 3200x2400, 4,729,810 bytes (4.5M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 500, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on April 24, 2010 06:34:38
Last modified on April 24, 2010 at 07:57
|
Picture #10: Kodak Pony Premo rear
Small: 900x698, 65,420 bytes (64K), (html file)
Large: 3600x2700, 5,921,470 bytes (5.6M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 640, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on April 24, 2010 06:38:49
Last modified on April 24, 2010 at 07:59
|
Picture #11: Kodak Pony Premo with film holder
Small: 900x698, 69,238 bytes (68K), (html file)
Large: 3600x2700, 6,178,158 bytes (5.9M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 800, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on April 24, 2010 06:39:27
Last modified on April 24, 2010 at 08:00
|
Picture #12: Kodak Pony Premo film holder
Small: 800x623, 51,830 bytes (51K), (html file)
Large: 3200x2400, 6,978,294 bytes (6.7M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-3 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 400, FL-36 flash, 1/60 sec, 23.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 46.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on April 24, 2010 06:42:17
Last modified on April 24, 2010 at 08:03
|
Picture #1: E-3 with focusing ring
Small: 1000x773, 146,294 bytes (143K), (html file)
Large: 4000x3000, 10,671,529 bytes (11M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/4.5, ISO 200, FL-36 flash, 1/60 sec, 22.0mm, auto mode, vivid color, SHQ, matrix metering, manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 44.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on September 09, 2010 10:43:44
Last modified on September 09, 2010 at 23:32
|
Picture #2: Homemade ring to focus 14-54mm in view camera shell
Small: 1000x773, 189,196 bytes (185K), (html file)
Large: 4000x3000, 13,535,365 bytes (13M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 22.0mm, aperture priority, vivid color, SHQ, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 44.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on September 09, 2010 10:44:44
Last modified on September 09, 2010 at 23:34
|
Picture #3: Prototype camera shell for E-3
Small: 1000x773, 115,022 bytes (113K), (html file)
Large: 4000x3000, 11,420,030 bytes (11M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/80 sec, 36.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 72.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:48:19
Last modified on September 09, 2010 at 23:37
|
Picture #4: Prototype camera shell for E-3 #2
Small: 1000x773, 108,673 bytes (107K), (html file)
Large: 4000x3000, 10,803,748 bytes (11M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/80 sec, 36.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 72.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on September 09, 2010 10:48:31
Last modified on September 09, 2010 at 23:39
|
Picture #5: Prototype camera shell for E-3 #3
Small: 800x623, 80,467 bytes (79K), (html file)
Large: 3200x2400, 7,081,302 bytes (6.8M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 17.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:50:33
Last modified on September 09, 2010 at 23:47
|
Picture #6: Prototype camera shell for E-3 #4
Small: 1000x773, 117,086 bytes (115K), (html file)
Large: 4000x3000, 11,194,151 bytes (11M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 17.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:50:54
Last modified on September 09, 2010 at 23:50
|
Picture #7: Prototype camera shell for E-3 #5
Small: 667x1023, 116,642 bytes (114K), (html file)
Large: 2000x3000, 5,817,386 bytes (5.5M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.6, ISO 200, FL-36 flash, 1/60 sec, 17.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:52:09
Last modified on September 09, 2010 at 23:54
|
Picture #8: Prototype camera shell for E-3 #6
Small: 1000x773, 130,897 bytes (128K), (html file)
Large: 4000x3000, 11,790,417 bytes (12M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.6, ISO 200, FL-36 flash, 1/60 sec, 17.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:54:59
Last modified on September 09, 2010 at 23:57
|
Picture #9: Prototype camera shell for E-3 #7
Small: 1000x773, 119,924 bytes (118K), (html file)
Large: 4000x3000, 11,639,827 bytes (12M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.6, ISO 200, FL-36 flash, 1/60 sec, 16.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 32.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:57:56
Last modified on September 09, 2010 at 23:59
|
Picture #10: Prototype camera shell for E-3 #8
Small: 1000x773, 118,731 bytes (116K), (html file)
Large: 4000x3000, 11,351,820 bytes (11M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.6, ISO 200, FL-36 flash, 1/60 sec, 16.0mm, aperture priority, vivid color, SHQ, flash (5500K), matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 32.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on September 09, 2010 10:58:15
Last modified on September 10, 2010 at 00:02
|
Picture #11: Cigar box before modification
Small: 1000x1023, 124,658 bytes (122K), (html file)
Large: 3000x3000, 7,483,430 bytes (7.1M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/4.9, ISO 200, FL-36 flash, 1/60 sec, 29.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 58.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 05, 2010 23:27:52
Last modified on November 06, 2010 at 01:03
|
Picture #12: Back view of E-3 and bellows with camera viewer
Small: 1000x773, 95,970 bytes (94K), (html file)
Large: 4000x3000, 8,152,771 bytes (7.8M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.1, ISO 200, FL-36 flash, 1/60 sec, 34.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 68.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 05, 2010 23:47:00
Last modified on November 06, 2010 at 01:21
|
Picture #13: Side view of E-3 and bellows with camera viewer
Small: 900x623, 79,136 bytes (78K), (html file)
Large: 3600x2400, 5,991,149 bytes (5.7M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/4.1, ISO 200, FL-36 flash, 1/60 sec, 17.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 05, 2010 23:47:37
Last modified on November 06, 2010 at 01:15
|
Picture #14: Front view of E-3 and bellows with camera viewer
Small: 1000x773, 101,933 bytes (100K), (html file)
Large: 4000x3000, 8,659,857 bytes (8.3M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/11.0, ISO 200, FL-36 flash, 1/60 sec, 34.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 68.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 06, 2010 00:39:05
Last modified on November 06, 2010 at 01:26
|
Picture #15: E-3, cigar box, bellows
Small: 1000x773, 107,327 bytes (105K), (html file)
Large: 4000x3000, 10,860,682 bytes (11M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm f/3.5-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 22.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 44.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 10, 2010 09:02:45
Last modified on November 10, 2010 at 10:21
|
Picture #16: E-3, cigar box, bellows #2
Small: 800x623, 73,584 bytes (72K), (html file)
Large: 3200x2400, 6,383,811 bytes (6.1M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm f/3.5-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 21.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 42.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 10, 2010 09:03:23
Last modified on November 10, 2010 at 10:24
|
Picture #17: E-3, cigar box, bellows #3
Small: 800x623, 81,632 bytes (80K), (html file)
Large: 3200x2400, 6,575,459 bytes (6.3M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm f/3.5-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 22.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 44.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 10, 2010 09:06:17
Last modified on November 10, 2010 at 10:26
|
Picture #18: E-3 cigar box camera with live view
Small: 1000x773, 109,453 bytes (107K), (html file)
Large: 4000x3000, 9,864,938 bytes (9.4M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm f/3.5-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 21.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 42.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 10, 2010 09:55:20
Last modified on November 10, 2010 at 10:28
|
Picture #19: E-3 cigar box camera with live view #2
Small: 900x623, 81,592 bytes (80K), (html file)
Large: 3600x2400, 8,598,494 bytes (8.2M), (html file)
Copyright, Michael Meissner 2010, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm f/3.5-5.6 lens
f/8.0, ISO 250, FL-36 flash, 1/60 sec, 16.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 32.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on November 10, 2010 09:56:03
Last modified on November 10, 2010 at 10:32
|
Picture #20: 8 and 6 inch unfinished boxes from Michaels
Small: 750x1023, 80,855 bytes (79K), (html file)
Large: 3000x4000, 8,921,815 bytes (8.5M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/80 sec, 42.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 84.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on January 03, 2011 22:19:34
Last modified on January 06, 2011 at 10:52
I'm using the larger shadow box as the base of the current shell for hiding the camera.
It is 8 inches tall/wide, and 3 3/4 inches deep.
At the moment, I'm not using the smaller 6 inch box.
|
Picture #21: Glueing the base
Small: 1000x773, 145,832 bytes (143K), (html file)
Large: 4000x3000, 12,359,480 bytes (12M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 320, FL-36 flash, 1/100 sec, 47.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 94.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 04, 2011 08:57:11
Last modified on January 06, 2011 at 10:58
|
Picture #22: Work in progress
Small: 1000x773, 127,430 bytes (125K), (html file)
Large: 4000x3000, 9,908,466 bytes (9.4M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 20.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 40.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on January 04, 2011 08:57:48
Last modified on January 06, 2011 at 10:59
|
Picture #23: Thumb vs. coping saw
Small: 1000x773, 92,865 bytes (91K), (html file)
Large: 4000x3000, 9,094,823 bytes (8.7M), (html file)
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 250, FL-36 flash, 1/60 sec, 16.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 32.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on January 06, 2011 09:29:04
Last modified on January 10, 2011 at 09:03
I was trying to shave a little bit off of the base so I could get the memory
card out without unscrewing the camera, and the coping saw slipped and cut my
thumb. Yeah, yeah, yeah, I should know better.
|
Picture #24: Picture frame for viewing the LCD
Small: 1000x773, 94,101 bytes (92K), (html file)
Large: 4000x3000, 9,142,889 bytes (8.7M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 29.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 58.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on January 06, 2011 09:31:51
Last modified on January 06, 2011 at 11:03
|
Picture #25: One impediment to working on the camera shell
Small: 1000x773, 114,482 bytes (112K), (html file)
Large: 4000x3000, 9,071,866 bytes (8.7M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 500, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: NoiseNinja, gimp
Taken by Michael Meissner on January 06, 2011 09:32:46
Last modified on January 06, 2011 at 11:11
|
Picture #26: Hole for memory card
Small: 800x623, 91,447 bytes (90K), (html file)
Large: 3200x2400, 7,447,754 bytes (7.1M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 320, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 08, 2011 12:49:21
Last modified on January 09, 2011 at 22:27
|
Picture #27: Construction of the shell
Small: 1000x773, 110,697 bytes (109K), (html file)
Large: 4000x3000, 9,445,517 bytes (9.0M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 22.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 44.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 08, 2011 12:50:09
Last modified on January 09, 2011 at 22:30
|
Picture #28: Construction of the shell #2
Small: 1000x773, 135,314 bytes (133K), (html file)
Large: 4000x3000, 10,287,206 bytes (9.8M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 250, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 09, 2011 20:30:09
Last modified on January 09, 2011 at 22:32
|
Picture #29: Construction of the shell #3
Small: 800x623, 92,011 bytes (90K), (html file)
Large: 3200x2400, 6,819,443 bytes (6.5M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 250, FL-36 flash, 1/60 sec, 20.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 40.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 09, 2011 20:30:26
Last modified on January 09, 2011 at 22:34
|
Picture #30: Hole for memory card #2
Small: 1000x773, 122,176 bytes (120K), (html file)
Large: 4000x3000, 10,537,313 bytes (11M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 09, 2011 20:38:01
Last modified on January 09, 2011 at 22:36
|
Picture #31: Hole for the battery
Small: 800x623, 95,007 bytes (93K), (html file)
Large: 3200x2400, 6,763,989 bytes (6.5M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on January 09, 2011 20:43:23
Last modified on January 09, 2011 at 22:38
|
Picture #32: Staining the box
Small: 1000x773, 134,169 bytes (132K), (html file)
Large: 4000x3000, 10,614,282 bytes (11M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 50.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: default crop, gimp
Taken by Michael Meissner on January 12, 2011 09:42:08
Last modified on January 12, 2011 at 10:16
|
Picture #33: Back of the camera shell used at Arisia 2011
Small: 800x623, 65,184 bytes (64K), (html file)
Large: 3200x2400, 4,324,685 bytes (4.1M), (html file)
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/4.3, ISO 200, FL-36 flash, 1/60 sec, 20.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 40.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp, neatimage
Taken by Michael Meissner on January 15, 2011 09:46:09
Last modified on January 21, 2011 at 19:20
|
Picture #34: Front of the camera shell used at Arisia 2011
Small: 800x623, 74,036 bytes (73K), (html file)
Large: 3200x2400, 4,537,592 bytes (4.3M), (html file)
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, FL-36 flash, 1/60 sec, 18.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 36.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp, neatimage
Taken by Michael Meissner on January 15, 2011 09:47:29
Last modified on January 21, 2011 at 19:25
|
Picture #35: Camera for Arisia 2011
Small: 900x698, 81,584 bytes (80K), (html file)
Large: 3600x2700, 5,666,247 bytes (5.4M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 200, Promaster flash, 1/60 sec, 29.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 58.0mm
Extra equipment used: Promaster 5750DX flash
Programs used: gimp, neatimage
Taken by Michael Meissner on January 15, 2011 14:20:46
Last modified on January 30, 2011 at 14:04
|
Picture #36: Camera for Arisia 2011 #2
Small: 900x698, 87,172 bytes (86K), (html file)
Large: 3600x2700, 5,668,092 bytes (5.4M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/4.1, ISO 200, Promaster flash, 1/60 sec, 17.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Promaster 5750DX flash
Programs used: gimp, neatimage
Taken by Michael Meissner on January 15, 2011 14:34:43
Last modified on January 30, 2011 at 14:08
|
Picture #37: Brass dragon with view camera
Small: 600x846, 74,108 bytes (73K), (html file)
Large: 1800x2400, 2,307,084 bytes (2.2M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.4, ISO 200, Promaster flash, 1/100 sec, 52.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 104.0mm
Extra equipment used: Promaster 5750DX flash
Programs used: gimp, neatimage
Taken by Michael Meissner on January 15, 2011 14:35:10
Last modified on January 30, 2011 at 14:10
|
Picture #38: Picture of me ready to go to Arisia 2011
Small: 600x846, 84,480 bytes (83K), (html file)
Large: 1800x2400, 3,394,327 bytes (3.2M), (html file)
Copyright, Gwendolyn Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/4.1, ISO 200, Promaster flash, 1/60 sec, 17.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Promaster 5750DX flash
Programs used: gimp
Taken by Gwendolyn Meissner on January 15, 2011 14:41:48
Last modified on January 30, 2011 at 14:13
|
Picture #39: Picture of me ready to go to Arisia 2011 #2
Small: 900x698, 91,615 bytes (90K), (html file)
Large: 3600x2700, 7,491,956 bytes (7.1M), (html file)
Copyright, Gwendolyn Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/5.3, ISO 200, Promaster flash, 1/80 sec, 39.0mm, auto mode, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 78.0mm
Extra equipment used: Promaster 5750DX flash
Programs used: gimp
Taken by Gwendolyn Meissner on January 15, 2011 14:42:06
Last modified on January 30, 2011 at 14:16
|
Picture #40: Building the camera shell with a hand saw router box
Small: 900x623, 99,127 bytes (97K), (html file)
Large: 3600x2400, 7,561,678 bytes (7.2M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 400, FL-36 flash (+0.33 flash compensation), 1/60 sec, 20.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 40.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on February 05, 2011 19:29:15
Last modified on February 05, 2011 at 22:04
After Arisia in 2011, I decided that changing the batteries was cumbersome, so
I bought an Olympus HLD-4 battery grip for my E-3. This in turn called for
using a bigger box, so I decided to build this box by hand.
|
Picture #41: Building the camera shell with a hand saw router box #2
Small: 900x698, 112,835 bytes (111K), (html file)
Large: 3600x2700, 8,858,416 bytes (8.4M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 320, FL-36 flash (+0.33 flash compensation), 1/60 sec, 17.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on February 05, 2011 21:14:53
Last modified on February 05, 2011 at 22:08
|
Picture #42: Preparing to glue the camera shell
Small: 900x623, 103,511 bytes (102K), (html file)
Large: 3600x2400, 7,397,111 bytes (7.1M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 500, FL-36 flash (+0.33 flash compensation), 1/60 sec, 17.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 34.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on February 05, 2011 21:29:28
Last modified on February 05, 2011 at 22:11
|
Picture #43: Done for the evening
Small: 900x623, 89,117 bytes (88K), (html file)
Large: 3600x2400, 8,204,961 bytes (7.8M), (html file)
Copyright, Michael Meissner 2011, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-150mm-II f/4.0-5.6 lens
f/8.0, ISO 320, FL-36 flash (+0.33 flash compensation), 1/60 sec, 20.0mm, aperture priority, vivid color, matrix metering, auto + manual focus, image stabilization, noise reduction auto
35mm equivalent focal length 40.0mm
Extra equipment used: Olympus FL-36 flash
Programs used: gimp
Taken by Michael Meissner on February 05, 2011 21:39:42
Last modified on February 05, 2011 at 22:15
|
Picture #44: Seneca Chautauqua, Kodak Pony Premo with E-P2, and Arisia camera
Small: 1000x773, 108,073 bytes (106K), (html file)
Large: 4000x3000, 2,698,781 bytes (2.6M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus VG-120 camera
f/2.8, ISO 125, flash, 1/30 sec, 4.7mm, auto mode, HQ, center weight metering
35mm equivalent focal length 26.0mm
Extra equipment used: popup flash
Programs used: raw therapee
Taken by Michael Meissner on January 23, 2012 20:45:01
Last modified on January 27, 2012 at 09:25
|
Picture #45: Seneca Chautauqua, Kodak Pony Premo with E-P2, and Arisia camera #2
Small: 1000x773, 116,564 bytes (114K), (html file)
Large: 4000x3000, 2,879,136 bytes (2.7M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus VG-120 camera
f/2.8, ISO 125, flash, 1/30 sec, 4.7mm, auto mode, HQ, center weight metering
35mm equivalent focal length 26.0mm
Extra equipment used: popup flash
Programs used: raw therapee
Taken by Michael Meissner on January 23, 2012 20:45:27
Last modified on January 27, 2012 at 09:25
|
Picture #46: Seneca Chautauqua, Kodak Pony Premo with E-P2, and Arisia camera #3
Small: 1000x773, 132,430 bytes (130K), (html file)
Large: 4000x3000, 3,052,201 bytes (2.9M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus VG-120 camera
f/2.8, ISO 125, flash, 1/30 sec, 4.7mm, auto mode, HQ, center weight metering
35mm equivalent focal length 26.0mm
Extra equipment used: popup flash
Programs used: raw therapee
Taken by Michael Meissner on January 23, 2012 20:45:50
Last modified on January 27, 2012 at 09:25
|
Picture #47: Using a telegraph to shoot pictures
Small: 1000x773, 140,030 bytes (137K), (html file)
Large: 4000x3000, 11,708,330 bytes (12M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus E-P2 camera with Olympus-m43 14-42mm f/3.5-5.6 lens
f/8.0, ISO 400, FL-36 flash (+0.33 flash compensation), 1/60 sec, 21.0mm, aperture priority, vivid color, SHQ, matrix metering, image stabilization, noise reduction auto, noise filter low
35mm equivalent focal length 42.0mm
Programs used: gimp
Taken by Michael Meissner on February 09, 2012 23:49:40
Last modified on February 20, 2012 at 10:03
|
Picture #48: Olympus E-P2 inside of Kodak Pony Premo 5x7
Small: 1000x773, 137,962 bytes (135K), (html file)
Large: 4000x3000, 3,119,656 bytes (3.0M), (html file)
Copyright, Michael Meissner 2012, All rights reserved
Olympus VG-120 camera
f/3.4, ISO 125, flash, 1/40 sec, 8.3mm, auto mode, HQ, center weight metering
35mm equivalent focal length 47.0mm
Programs used: crop, raw therapee
Taken by Michael Meissner on January 23, 2012 20:48:15
Last modified on February 25, 2012 at 11:02
|
Picture #1: Olympus E-PM2 with Brown Gariz genuine leather half case
Small: 1000x773, 160,528 bytes (157K), (html file)
Large: 4000x3000, 10,749,174 bytes (11M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 33.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 66.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:38:19
Last modified on March 17, 2013 at 13:09
|
Picture #2: Olympus E-PM2 with Brown Gariz genuine leather half case #2
Small: 1000x773, 125,951 bytes (123K), (html file)
Large: 4000x3000, 9,980,646 bytes (9.5M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 33.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 66.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:38:34
Last modified on March 17, 2013 at 13:11
|
Picture #3: Olympus E-PM2 with Brown Gariz genuine leather half case #3
Small: 1000x773, 120,452 bytes (118K), (html file)
Large: 4000x3000, 9,619,158 bytes (9.2M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 44.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 88.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:38:49
Last modified on March 17, 2013 at 13:13
|
Picture #4: Olympus E-PM2 with Brown Gariz genuine leather half case #4
Small: 1000x773, 111,519 bytes (109K), (html file)
Large: 4000x3000, 8,476,759 bytes (8.1M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 45.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 90.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:39:04
Last modified on March 17, 2013 at 13:14
|
Picture #5: Olympus E-PM2 with Brown Gariz genuine leather half case #5
Small: 1000x773, 103,568 bytes (102K), (html file)
Large: 4000x3000, 8,737,856 bytes (8.3M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 45.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 90.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:39:13
Last modified on March 17, 2013 at 13:16
|
Picture #6: Olympus E-PM2 with Brown Gariz genuine leather half case #6
Small: 1000x773, 125,576 bytes (123K), (html file)
Large: 4000x3000, 10,265,436 bytes (9.8M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 32.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 64.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:40:07
Last modified on March 17, 2013 at 13:18
|
Picture #7: Olympus E-PM2, Gariz half leather case, Peak Design camera capture
Small: 1000x773, 117,158 bytes (115K), (html file)
Large: 4000x3000, 9,987,495 bytes (9.5M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/9.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 25.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 50.0mm
Extra equipment used: Metz 48 AF-1 flash
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:48:09
Last modified on March 17, 2013 at 13:28
|
Picture #8: Olympus E-PM2, Gariz half leather case, Pistol grip shutter release
Small: 1000x773, 75,460 bytes (74K), (html file)
Large: 4000x3000, 7,279,149 bytes (6.9M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/8.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 29.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 58.0mm
Extra equipment used: Metz 48 AF-1
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 12:42:32
Last modified on March 17, 2013 at 19:53
|
Picture #9: Olympus E-PM2, Gariz half leather case, Pistol grip shutter release #2
Small: 1000x773, 205,211 bytes (201K), (html file)
Large: 4000x3000, 7,495,898 bytes (7.1M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/9.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 27.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 54.0mm
Extra equipment used: Metz 48 AF-1
Programs used: crop, rawtherapee
Taken by Michael Meissner on March 17, 2013 19:27:28
Last modified on March 17, 2013 at 19:54
|
Picture #10: Olympus E-PM2, Gariz half leather case, Pistol grip shutter release #3
Small: 1000x773, 156,395 bytes (153K), (html file)
Large: 4000x3000, 7,490,139 bytes (7.1M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/9.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 27.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 54.0mm
Extra equipment used: Metz 48 AF-1
Programs used: crop, rawtherapee
Taken by Michael Meissner on March 17, 2013 19:27:55
Last modified on March 17, 2013 at 19:55
|
Picture #11: Comparing Gariz E-PM2 leather half case to Aki-Asahi leather half E-P2 case
Small: 1000x773, 134,721 bytes (132K), (html file)
Large: 4000x3000, 10,095,465 bytes (9.6M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/9.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 28.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 56.0mm
Extra equipment used: Metz 48 AF-1
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 19:33:44
Last modified on March 17, 2013 at 20:02
|
Picture #12: Comparing Gariz E-PM2 leather half case to Aki-Asahi leather half E-P2 case #2
Small: 1000x773, 134,094 bytes (131K), (html file)
Large: 4000x3000, 10,096,740 bytes (9.6M), (html file)
Copyright, Michael Meissner 2013, All rights reserved
Olympus E-5 camera with Olympus 14-54mm f/2.8-3.5 lens
f/9.0, ISO 200, Metz 48 flash (+0.3 flash compensation), 1/60 sec, 35.0mm, aperture priority, vivid color, matrix metering, image stabilization
35mm equivalent focal length 70.0mm
Extra equipment used: Metz 48 AF-1
Programs used: crop, gimp
Taken by Michael Meissner on March 17, 2013 19:34:25
Last modified on March 17, 2013 at 20:06
|
